Somat eDAQ
lite
54
I2773-4.4 en
Use PC Card memory for remote RAM disk storage
Store the static part of the RAM disk file on the PC Card. This effectively limits the size
of the RAM disk file and helps prevent a situation where the RAM disk memory fills up
before the PC Card memory.
NOTE
When this option is selected, the ability to upload individual test runs is disabled.
Use default sample rate/filter for all low level calibrations
Not applicable to the eDAQ
lite
.
Shunt calibration mode options
Not applicable to the eDAQ
lite
.
Enable Backup Battery Interlocks on Test Runs
Select this option to enable the backup battery option in the ELCPU configuration
options by default. For more information battery interlocks, see “Battery Power” on
page 32.
3.2.4 Remote Test Run Control
The remote control setup preferences configure the eDAQ
lite
for remote control of
test runs using digital input and output lines. The eDAQ
lite
uses the digital input and
output lines on the lowest addressed ELDIO layer for remote control operation.
After selecting Remote Test Run Control from the Preferences menu, choose the
eDAQ
lite
option to modify the following preferences. For more information remote test
control, see “Using Remote Control Operation” on page 85.
NOTE
Changing these preferences after a test is initialized does not affect the remote control
operation for the test currently in progress.
Modify current test setup settings only
Change the remote control parameters in the current test setup only. When this option
is disabled, all parameters are saved as TCE defaults. TCE applies the default settings
to all new setup files and files without defined remote control parameters. Previously
defined parameters retain their values taking precedence over the application defaults.
Control mode
Select the desired remote control mode.
HBM: public
