For more information on setting up a computed channel, see “Creating Channels and
DataModes™” on page 61. For information on specific computed channel types, see
“Computed Channels” on page 129.
DataMode Setup
Use the DataMode window to define the DataMode configuration required for the test.
A DataMode definition consists of a list of input channels, a data sampling rate,
triggering mode and conditions and other DataMode specific parameters.
For more information on setting up a DataMode, see “Creating Channels and
DataModes™” on page 61. For information on specific DataMode types, see
“DataModes™” on page 161.
3.1.2 Pull Down Menus
The following table describes the menu options available in TCE. Where applicable,
the last column provides a section number in this document for more information on
the menu command.
NOTE
To perform any tasks in the FCS Setup menu, the PC must be connected to the
eDAQ
lite specified in the TCE communications preferences.
Option Description
Add Add a new computed channel definition to the setup. TCE adds the
new computed channel above the selected entry.
Del Delete the selected computed channels.
Edit Modify the selected computed channel definition.
Copy Copy the selected computed channel definition into a new computed
channel. TCE adds the new channel below the selected entry.
Option Description
Add Add a new DataMode definition to the setup. TCE adds the new
DataMode above the selected entry.
Del Delete the selected DataModes definitions.
Edit Modify the selected DataMode definition.
Copy Copy the selected DataMode definition into a new DataMode
definition. TCE adds the new channel below the selected entry.
Mem Display the SIF data raw memory allocated for the selected DataMode
definition.
