Enable Triggered Reset
Select the triggered reset option to enable triggered resets of the tracker.
NOTE
Resetting the tracker sets the minimum value to the current sample value.
Trigger Channel
If using the reset enable feature, specify the desired trigger channel.
Trigger Mode
If using the reset enable feature, specify one of three available trigger reset modes.
7.5.3 Range Track
The Range Track channel generates an output channel that tracks the range of the
input channel. A logical channel specified as a trigger can reset the output channel
tracking.
Input Channel
The input channel data type must be 32-bit float or 16-bit integer.
Output Data Type
The output data type is 32-bit float if the input channel data type is 32-bit float and
16-bit unsigned if the input channel data type is 16-bit integer.
Enable Triggered Reset
Select the triggered reset option to enable triggered resets of the tracker.
NOTE
Resetting the tracker sets the range value to zero.
Trigger Channel
If using the reset enable feature, specify the desired trigger channel.
Trigger Mode
If using the reset enable feature, specify one of three available trigger reset modes.
Trigger Mode Description
When TRUE Reset when the trigger channel is TRUE.
On FALSE-TRUE edge Reset when the trigger transitions from FALSE to TRUE.
On TRUE-FALSE edge Reset on the sample after the trigger channel transitions from
TRUE to FALSE.
