I2773-4.4 en
57
Somat eDAQ
lite
Show strip chart grid lines
Activate visible grid lines on the strip chart plot.
3.2.7 Group DVM Display
Select one of three display modes for group DVM displays.
3.2.8 Auto Range Options
NOTE
Access the auto range options from the Test Control menu.
NOTE
Automatically chain this task to the stop run task using TCE General Preferences.
Use the auto range options to acquire the minimum and maximum values for all
channels stored in Time History DataMode in the eDAQ
lite
resident SIE or SIF file.
This includes all transducer channels and all computed channels that have the
full-scale values defined. The information is displayed on a run-by-run basis. The initial
dialog window presents the results from the last run. Select to display other runs as
desired.
The channels are sorted in the order of full-scale saturation percent (i.e., how close
the channel is to either of the user-defined full-scale limits). This option is available
whenever the SIE or SIF data file is resident in the eDAQ
lite
.
Option Description
Normal The signal trace begins again at the left side of the plot.
Scroll The signal trace scrolls continuously to the left at the rate at which data
is received and with the current value at the right edge.
Mixed The right half of the signal trace moves to the left half of the plot and
the signal trace continues from the middle of the plot.
Option Description
Original Static Use static control fields and limit to a maximum of 16 channels.
Scroll List Use a scrollable list control with sizable fields: channel ID, current
value and units. Limit to a maximum of 256 channels.
Scroll List Extended Use a scrollable list control with sizable fields: network, connector ID,
channel ID, current value, saturation bounds and units. Limit to a
maximum of 256 channels.
HBM: public
