Somat eDAQlite - ELBRG Analog Input

Somat eDAQ lite
208
I2773-4.4 en
13.3.2 ELBRG Analog Input
Use the Somat SAC-TRAN-MP Transducer Cable (1-SAC-TRAN-MP-2-2 or
1-SAC-TRAN-MP-10-2) to wire ELBRG analog inputs.
NOTE
Do not use this wiring diagram for ELHLS channels.
Figure 13-12: Wiring diagram for a standard analog input on an ELBRG layer.
5KIPCN
5KIPCN
YJKVG
ITGGP
8
DCTG
5JKGNF)TQWPF
'.$4)
5#%64#0/2


