Somat eDAQlite - ELBRG (Bridge Layer); ELBRG Bridge Transducers

Somat eDAQ lite
206
I2773-4.4 en
Figure 13-7: Wiring diagram for a half-bridge configuration using a Strain SMART Module.
Figure 13-8: Wiring diagram for a quarter-bridge configuration using a Strain SMART
Module.
NOTE
For the SMSTRB4, the brown lead wire is routed to the internal completion resistor.
For the older fixed quarter-bridge SMART modules (i.e., modules with serial numbers
starting with SMSTRQB), the white lead wire is routed to the internal completion
resistor.
13.3 ELBRG (Bridge Layer)
13.3.1 ELBRG Bridge Transducers
Use the Somat SAC-TRAN-MP Transducer Cable (1-SAC-TRAN-MP-2-2 or
1-SAC-TRAN-MP-10-2) to wire ELBRG bridge transducer inputs.
'ZEKVCVKQP
5KIPCN
'ZEKVCVKQP
TGF
ITGGP
DNCEM
5/564$
'.*.5
5#%':6/(
5#%64#0/2
'ZEKVCVKQP
5KIPCN
VQKPVGTPCN
EQORNGVKQPTGUKUVQT
TGF
ITGGP
DTQYP
5/564$
'.*.5
5#%':6/(
5#%64#0/2
