Somat eDAQ lite
1 Getting Started
1.1 Overview
The Somat eDAQ lite is a sealed, stand-alone, microprocessor-based data acquisition
system designed for portable data collection in the harshest of environments. It has
leading-edge signal conditioning and a capacity to perform a broad range of on-board
data processing. Engineered to be rugged and mobile, the eDAQ
lite is tested to
military standards at 10 g’s from 55 to 2000 Hz. Internal back-up batteries protect the
eDAQ
lite from unplanned power losses or low voltage events. Hundreds of
synchronous channels are possible in a single system with virtually limitless channel
counts when networking multiple systems using Ethernet communications.
1.1.1 eDAQ lite Layers
The eDAQ lite consists of one base processor layer and a number of optional add-on
layers. The following table lists the available layers, including the base processor.
1.2 Equipment
This section describes the provided equipment and the support equipment necessary
to set up the eDAQ
lite system and run a test.
1.2.1 Provided Equipment
The initial shipment of a basic eDAQ lite contains the hardware listed below; additional
hardware may be included based on options ordered. The eDAQ
lite also comes with
Somat Test Control Environment (TCE) software.
NOTE
If any items do not arrive as expected, contact your system supplier, nearest HBM
sales representative or HBM immediately.
Name Order Number Description
ELCPU 1-ELCPU-2 eDAQ lite Base Processor
1-ELCPU-PLUS-2 eDAQ lite Base Processor with Extended Voltage
ELCOM 1-ELCOM-2 eDAQ lite Vehicle Network Communications Layer
ELHLS 1-ELHLS-2 eDAQ lite High Level Analog Layer
ELBRG 1-ELBRG-350-2 eDAQ lite Bridge Layer; 350-Ohm
1-ELBRG-120-2 eDAQ lite Bridge Layer; 120-Ohm
ELDIO 1-ELDIO-B-2 eDAQ lite Digital Input/Output Layer
1-ELDIO-5HZGPS-2 eDAQ lite Digital Input/Output Layer with GPS
ELNTB 1-ELNTB-2 eDAQ lite Non-Isolated Thermocouple Layer
ELBAT 1-ELBAT-2 eDAQ lite Battery Layer
