4.5 Viewing Channel Displays
TCE includes a variety of integrated run-time displays to view real-time data from input
channels and computed channels during a test run. TCE also offers a several signal
display types to view transducer input signals when a test run is not in progress.
Category Indicator Description
Test Run Status Test Initialized Indicates that a test is initialized on the eDAQ
lite
.
Remote Control If a test is initialized, indicates the status of the remote control mode as
either disabled, enabled or suspended.
Run # If a test is initialized, indicates the current run number or the next run
number if no test is running.
Run or Preview Started Indicates that a test run or preview is in progress.
Run Time If a test run or preview is in progress, indicates the elapsed time since the
start of the run. The elapsed time display rolls over after 1000 hours.
Post Run Tasks Indicates that a test run is stopped, but the required post run tasks are not
completed.
RAM Disk Files Origin Indicates the original TCE name of the current test setup file.
Setup Indicates the eDAQ
lite
reference name of the current test setup file.
Data Indicates the name of the current SIF data file. Note that even when using
only SIE data, the eDAQ
lite
retains a very small RAM disk-based SIF file
for internal purposes.
RAM Disk Memory
(in bytes and percent total of
RAM disk memory)
Total Indicates the total RAM disk memory on the eDAQ
lite
.
SIF File Indicates the current size of the resident SIF data file.
Unused Indicates the unused memory available for data file storage.
PC Card Disk Memory
(in bytes and percent of total
PC Card memory)
Total Indicates the total memory on the PC Card.
SIE File Indicates the cumulative size of the SIE data files currently on the PC
Card.
SIF File Indicates the cumulative size of the SIF component data files current on
the PC Card.
Unused Indicates the unused memory on the PC Card available for data file
storage.
SIF File limited to Indicates the maximum allowable size for the SIF file.
SIF File Built on PC Card If PC Card data storage is in use, indicates that the SIF file has been
consolidated and the PC Card can be removed from the eDAQ
lite
after
powering down.
