Somat eDAQ
lite
28
I2773-4.4 en
Updating ELCPU Firmware
To update the ELCPU (MPB) firmware:
1. Power cycle the eDAQ
lite
.
2. Open the eDAQ
lite
web interface to the Hardware tab and click on the Code
column for the MPB. For more information on the eDAQ
lite
web interface, see
“eDAQlite Web Interface” on page 175.
3. Browse to the correct firmware file on the PC and click Update. Wait for the
eDAQ
lite
to return to the ready state.
4. Refresh the web interface as it may change with the new firmware.
Updating Layer Level Firmware
To update layer level firmware:
1. Open the eDAQ
lite
web interface to the hardware table and click on the Code
column for the desired layer. For more information on the eDAQ
lite
web interface,
see “eDAQlite Web Interface” on page 175.
2. Browse to the correct firmware file on the PC and click Update. Wait for the
application verified message indicating a successful update.
3. If no other firmware updates are required, cycle the power on the eDAQ
lite
to
complete the overall firmware update process.
NOTE
For more detailed procedures for each layer type and a listing of the current layer level
firmware versions see the instructions for installing eDAQ
lite
firmware provided with
the firmware installation.
2.2 Communications
2.2.1 Communications Methods
Ethernet Communications
Connect the eDAQ
lite
to the support PC directly using the provided crossover cable
(1-E-Ethernet X/O-2) or through a network using the optional hub cable
(1-E-Ethernet HUB-2). Using a network removes proximity restrictions on the
eDAQ
lite
and support PC.
Data transfer rates of up to 4 MB per second are possible using the 100BASE-T
Ethernet connection for communications between the eDAQ
lite
and the support PC.
A 100BASE-T compatible Ethernet card must be installed in the support PC.
In some cases, it may be helpful to change the Ethernet link mode:
To change the Ethernet link mode:
1. Establish communication between the eDAQ
lite
and the support PC.
2. Navigate to the system tab of the eDAQ web interface and click Ethernet Link
Setup.
