Input bit assignment
Select the desired run/stop control bit. If the line for this bit is high (logical 1), a test run
starts; when the line goes low (logical 0), the test run stops.
NOTE
With the remote control mode in use, all digital input lines for the ELDIO can function
as normal digital inputs.
Optional output bit assignments
There are four status outputs available; all are optional.
NOTE
To support remotely powered LED indicators, the eDAQ
lite
switches output lines to
ground for the on state and to open circuit for the off state.
NOTE
When using any of the optional output bits for eDAQ
lite
remote control operation,
digital outputs are always available but cannot be assigned to any bits used for remote
control outputs.
Option Description
Disable Do not use remote control.
Enable Use remote control for all subsequent tests.
Query Choose whether to use remote control at each test initialization.
Output Description
Running Indicates the test running state. Flashing indicates running, steady on
indicates starting or stopping a run and steady off indicates no test run
in progress.
Alarm Indicates a serious error or user alarm. TCE always reports the
specific error or warning condition on the next interaction with the
eDAQ
lite
. Note that running out of either RAM or PC Card memory
sets this alarm.
RAM Low % Indicates when the available RAM disk memory falls below the
user-specified limit.
PCM Low % Indicates when the available PC Card memory falls below the
user-specified limit.
