I2773-4.4 en
53
Somat eDAQ
lite
Check actual full scales
Force TCE to check the actual full-scale limits for all selected channels defined in the
test. Choose to check ELHLS or ELBRG channels. TCE performs the check
immediately after test initialization and reports if the over range protection meets the
conditions below. For more information on full-scale values, see “Full-Scale Values”
on page 108.
Enable min-max tracking for Time History DataModes
Track min and max values for each input channel in a Time History DataMode. This
option is not recommended for optimum throughput performance, but it is required to
support TCE auto range functionality. For more information on auto range options, see
“Auto Range Options” on page 57.
Option Description
SIE (delete old SIE
files on test init)
Collect data in the SIE file format and limit the number of SIE files on
the eDAQ
lite
to one, emulating the behavior of SIF files.
SIE Collect data in the SIE file format and allow multiple SIE files on the
eDAQ
lite
at the same time.
SIF Collect data in the SIF file format. Only one SIF file is allowed on the
eDAQ
lite
at one time.
Option Description
Low Level Not applicable to the eDAQ
lite
.
High Level SS Warn if over range protection on ELHLS channels is less than 1% or
greater than 25%.
Bridge Warn if over range protection on ELBRG channels is less than 1% or
greater than 25%.
HBM: public
