Somat eDAQ
lite
174
I2773-4.4 en
Stop Run Action
For each digital output, select the desired action when the test run stops.
Output Mode
Each digital output has five available output modes. The sample interval is the time
period associated with the sample rate of the input channels. Since the input channels
defined in the data mode can have different sample rates, the sample interval can vary
from channel to channel. The abbreviation used in the channel definition is in
parentheses.
Stop Run Action Description
No Action Do not change the output line when the test run stops.
Set Hi Set the output line to high (TRUE) when the test run stops.
Set Lo Set the output line to low (FALSE) when the test run stops.
Output Mode Description
Normal-Unlatched (N-U) Output TRUE if the sample interval contains a TRUE value;
otherwise, output FALSE.
Invert-Unlatched (I-U) Output FALSE if the sample interval contains a TRUE value;
otherwise, output TRUE.
Normal-Latched (N-L) Output TRUE and hold through the end of the test if the sample
interval contains a TRUE value.
Invert-Latched (I-L) Output FALSE and hold through the end of the test if the sample
interval contains a TRUE value.
Toggle-Latched (T-L) Toggle output between TRUE and FALSE for every sample
interval containing a TRUE value. The toggle rate is nominally
one second.
HBM: public
