I2773-4.4 en
193
Somat eDAQ
lite
Computed Channel
(continued)
Range Track 32-bit float
16-bit integer
32-bit float for 32-bit float input,
16-bit unsigned for 16-bit integer input
Smoothing Filter 32-bit float
16-bit integer
same as input
State Mapper 32-bit float 32-bit float
Statistical Analysis 32-bit float 32-bit float
Test Run Stopper 8-bit unsigned (logic) 8-bit unsigned (logic)
Time Base Shifter all same as input
Time Channel all 32-bit float
32-bit unsigned
Timed Trigger 8-bit unsigned (logic) 8-bit unsigned (logic)
Trigger Generator all 8-bit unsigned (logic)
Triggered Latch 32-bit float
32-bit integer
32-bit unsigned
same as input
Triggered Zero Suppression 32-bit float
32-bit integer
32-bit unsigned
same as input
Up Sampler all same is input
Over Range Detector
all 8-bit unsigned (logic)
Category Channel Type Input Data Type Output Data Type
HBM: public
Valid Data Gate all 8-bit unsigned (logic)
