6-22
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
R5520 1-216-864-11 METAL CHIP 0 5% 1/16W
R5521 1-216-864-11 METAL CHIP 0 5% 1/16W
R5523 1-216-809-11 METAL CHIP 100 5% 1/16W
R5524 1-216-809-11 METAL CHIP 100 5% 1/16W
R5525 1-216-809-11 METAL CHIP 100 5% 1/16W
R5551 1-216-841-11 METAL CHIP 47K 5% 1/16W
R5553 1-216-821-11 METAL CHIP 1K 5% 1/16W
R5557 1-216-864-11 METAL CHIP 0 5% 1/16W
R5560 1-216-853-11 METAL CHIP 470K 5% 1/16W
R5562 1-216-833-91 RES-CHIP 10K 5% 1/16W
R5563 1-216-841-11 METAL CHIP 47K 5% 1/16W
R5564 1-216-857-11 METAL CHIP 1M 5% 1/16W
R5565 1-216-857-11 METAL CHIP 1M 5% 1/16W
R5569 1-216-848-11 METAL CHIP 180K 5% 1/16W
R5608 1-216-864-11 METAL CHIP 0 5% 1/16W
R5609 1-216-833-91 RES-CHIP 10K 5% 1/16W
R5610 1-216-055-00 METAL CHIP 1.8K 5% 1/10W
R5611 1-216-845-11 METAL CHIP 100K 5% 1/16W
R5612 1-216-834-11 METAL CHIP 12K 5% 1/16W
R5613 1-216-055-00 METAL CHIP 1.8K 5% 1/10W
R5614 1-216-833-91 RES-CHIP 10K 5% 1/16W
R5616 1-216-810-11 METAL CHIP 120 5% 1/16W
R5617 1-216-837-11 METAL CHIP 22K 5% 1/16W
R5618 1-216-817-11 METAL CHIP 470 5% 1/16W
R5702 1-216-822-11 METAL CHIP 1.2K 5% 1/16W
R5704 1-216-823-11 METAL CHIP 1.5K 5% 1/16W
R5706 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R5707 1-216-828-11 METAL CHIP 3.9K 5% 1/16W
R5708 1-216-832-11 METAL CHIP 8.2K 5% 1/16W
R5711 1-216-809-11 METAL CHIP 100 5% 1/16W
R5712 1-216-855-11 METAL CHIP 680K 5% 1/16W
R5714 1-216-809-11 METAL CHIP 100 5% 1/16W
< SWITCH >
S5701 1-692-088-41 SWITCH, TACTILE (LCD BRIGHT +)
S5702 1-692-088-41 SWITCH, TACTILE (LCD BRIGHT -)
S5703 1-692-088-41 SWITCH, TACTILE (VOLUME +)
S5704 1-692-088-41 SWITCH, TACTILE (VOLUME -)
< TRANSFORMER >
0 T5601 1-435-226-11 TRANSFORMER, INVERTER
************************************************************
A-7074-158-A PJ-99 BOARD, COMPLETE(TR317/TR517)
*********************************
(Ref.No.;1000 Series)
< CAPACITOR >
C101 1-110-569-11 TANTAL. CHIP 47uF 20% 6.3V
C103 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
< CONNECTOR >
CN101 1-779-330-21 CONNECTOR, FFC/FPC 12P
< DIODE >
D101 8-719-062-16 DIODE 01ZA8.2(TPL3)
D105 8-719-988-61 DIODE 1SS355TE-17
< JACK >
J101 1-537-747-41 TERMINAL BOARD
< COIL >
L101 1-216-295-91 SHORT 0 (Note)
L102 1-412-963-11 INDUCTOR 100uH
< TRANSISTOR >
Q101 8-729-101-07 TRANSISTOR 2SB798-T1-DLDK
Q102 8-729-037-52 TRANSISTOR 2SC4738F-Y/GR(TPL3)
< RESISTOR >
R102 1-216-138-00 METAL CHIP 3.3 5% 1/8W
R103 1-216-830-11 METAL CHIP 5.6K 5% 1/16W
R104 1-216-820-11 METAL CHIP 820 5% 1/16W
R105 1-216-836-11 METAL CHIP 18K 5% 1/16W
R109 1-216-821-11 METAL CHIP 1K 5% 1/16W
< VARISTOR >
VDR101 1-801-862-11 VARISTOR, CHIP
VDR102 1-801-862-11 VARISTOR, CHIP
************************************************************
A-7074-122-A PJ-100 BOARD, COMPLETE (TRV67)
*****************************
A-7074-128-A PJ-100 BOARD, COMPLETE (TRV87/TRV87P)
************************************
A-7074-115-A PJ-100 BOARD, COMPLETE
(TRV17/TRV37/TRV47/TRV57/TRV57P)
**************************************
(Ref.No.;1000 Series)
< CAPACITOR >
C101 1-110-569-11 TANTAL. CHIP 47uF 20% 6.3V
C103 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
(TRV17/TRV37/TRV47/TRV57/TRV57P)
< CONNECTOR >
CN101 1-779-330-21 CONNECTOR, FFC/FPC 12P
< DIODE >
D101 8-719-045-87 DIODE MA4Z082WA-(K8).SO
(TRV17/TRV37/TRV47/TRV57/TRV57P/
TRV67/TRV87/TRV87P)
D102 8-719-073-03 DIODE MA8082-(K8).S0
(TRV67/TRV87/TRV87P)
D103 8-719-062-16 DIODE 01ZA8.2(TPL3)
(TRV67/TRV87/TRV87P)
D103 8-719-045-87 DIODE MA4Z082WA-(K8).SO
(TRV67/TRV87/TRV87P)
D104 8-719-062-16 DIODE 01ZA8.2(TPL3)
(TRV67/TRV87/TRV87P)
D104 8-719-045-87 DIODE MA4Z082WA-(K8).SO
(TRV67/TRV87/TRV87P)
D105 8-719-988-61 DIODE 1SS355TE-17
PD-117 PJ-99 PJ-100
Note : Resistor is mounted to the location where L101 is printed.
Note :
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
Note :
Les composants identifiés par
une marque 0 sont critiques
pour la sécurité.
Ne les remplacer que par une
pièce portant le numéro spécifié.
To Next Page
