6-23
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
< JACK >
J101 1-537-747-41 TERMINAL BOARD
(TRV17/TRV37/TRV47/TRV57/TRV57P)
J101 1-537-747-21 TERMINAL BOARD (TRV87/TRV87P)
J101 1-694-643-11 TERMINAL BOARD (TRV67)
< COIL >
L101 1-216-295-91 SHORT 0 (Note)
L102 1-216-295-91 SHORT 0 (Note)
(TRV67/TRV87/TRV87P)
L102 1-412-963-11 INDUCTOR 100uH
(TRV17/TRV37/TRV47/TRV57/TRV57P)
L103 1-216-295-91 SHORT 0 (Note) (TRV87/TRV87P)
L104 1-216-295-91 SHORT 0 (Note) (TRV87/TRV87P)
< TRANSISTOR >
Q101 8-729-101-07 TRANSISTOR 2SB798-T1-DLDK
Q102 8-729-037-52 TRANSISTOR 2SD2216J-QR(K8).SO
< RESISTOR >
R102 1-216-138-00 METAL CHIP 3.3 5% 1/8W
R103 1-216-830-11 METAL CHIP 5.6K 5% 1/16W
R104 1-216-820-11 METAL CHIP 820 5% 1/16W
R105 1-216-836-11 METAL CHIP 18K 5% 1/16W
R108 1-216-821-11 METAL CHIP 1K 5% 1/16W
(TRV67/TRV87/TRV87P)
R109 1-216-821-11 METAL CHIP 1K 5% 1/16W
< VARISTOR >
VDR101 1-801-862-11 VARISTOR, CHIP
VDR102 1-801-862-11 VARISTOR, CHIP (TRV87/TRV87P)
************************************************************
A-7074-123-A SE-101 BOARD, COMPLETE
(TRV57/TRV57P/TRV67)
**************************************
A-7074-129-A SE-101 BOARD, COMPLETE (TRV87/TRV87P)
************************************
A-7074-116-A SE-101 BOARD, COMPLETE
(TRV17/TRV37/TRV47)
**************************************
(Ref.No.;1000 Series)
< CAPACITOR >
C451 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
(TRV57/TRV57P/TRV67/TRV87/TRV87P)
C452 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
(TRV57/TRV57P/TRV67/TRV87/TRV87P)
C453 1-104-847-11 TANTAL. CHIP 22uF 20% 4V
(TRV57/TRV57P/TRV67/TRV87/TRV87P)
C454 1-104-847-11 TANTAL. CHIP 22uF 20% 4V
(TRV57/TRV57P/TRV67/TRV87/TRV87P)
C455 1-164-343-11 CERAMIC CHIP 0.056uF 10% 25V
(TRV57/TRV57P/TRV67/TRV87/TRV87P)
C456 1-164-343-11 CERAMIC CHIP 0.056uF 10% 25V
(TRV57/TRV57P/TRV67/TRV87/TRV87P)
C457 1-164-343-11 CERAMIC CHIP 0.056uF 10% 25V
(TRV57/TRV57P/TRV67/TRV87/TRV87P)
C458 1-110-666-11 ELECT CHIP 22uF 20% 6.3V
(TRV57/TRV57P/TRV67/TRV87/TRV87P)
C459 1-164-343-11 CERAMIC CHIP 0.056uF 10% 25V
(TRV57/TRV57P/TRV67/TRV87/TRV87P)
C460 1-110-666-11 ELECT CHIP 22uF 20% 6.3V
(TRV57/TRV57P/TRV67/TRV87/TRV87P)
C462 1-110-501-11 CERAMIC CHIP 0.33uF 10% 16V
(TRV57/TRV57P/TRV67/TRV87/TRV87P)
C463 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
(TRV57/TRV57P/TRV67/TRV87/TRV87P)
C464 1-127-688-21 TANTAL. CHIP 10uF 20% 6.3V
(TRV57/TRV57P/TRV67/TRV87/TRV87P)
< CONNECTOR >
CN451 1-691-348-11 CONNECTOR, FFC/FPC (ZIF) 10P
< IC >
IC451 8-759-489-19 IC uPC6756GR-8JG-E2
(TRV57/TRV57P/TRV67/TRV87/TRV87P)
< JACK >
J451 1-695-514-11 JACK (SMALL TYPE) 1P (HEADPHONE MONO)
(TRV17/TRV37/TRV17/TRV37/TRV47/
TRV57/TRV57P/TRV67)
J451 1-695-514-21 JACK (SMALL TYPE) 1P(HEADPHONE,STEREO)
(TRV87/TRV87P)
< COIL >
L451 1-414-754-11 INDUCTOR 10uH
(TRV57/TRV57P/TRV67/TRV87/TRV87P)
L452 1-216-295-91 SHORT 0 (Note)(TRV87/TRV87P)
L453 1-216-295-91 SHORT 0 (Note)
< RESISTOR >
R451 1-216-837-11 METAL CHIP 22K 5% 1/16W
(TRV57/TRV57P/TRV67/TRV87/TRV87P)
R452 1-216-837-11 METAL CHIP 22K 5% 1/16W
(TRV57/TRV57P/TRV67/TRV87/TRV87P)
R453 1-216-837-11 METAL CHIP 22K 5% 1/16W
(TRV57/TRV57P/TRV67/TRV87/TRV87P)
R454 1-216-837-11 METAL CHIP 22K 5% 1/16W
(TRV57/TRV57P/TRV67/TRV87/TRV87P)
R455 1-216-857-11 METAL CHIP 1M 5% 1/16W
(TRV57/TRV57P/TRV67/TRV87/TRV87P)
R456 1-216-833-91 RES-CHIP 10K 5% 1/16W
(TRV57/TRV57P/TRV67/TRV87/TRV87P)
R457 1-216-833-91 RES-CHIP 10K 5% 1/16W
(TRV57/TRV57P/TRV67/TRV87/TRV87P)
R458 1-216-857-11 METAL CHIP 1M 5% 1/16W
(TRV57/TRV57P/TRV67/TRV87/TRV87P)
R460 1-216-835-11 METAL CHIP 15K 5% 1/16W
(TRV57/TRV57P/TRV67/TRV87/TRV87P)
R461 1-216-864-11 METAL CHIP 0 5% 1/16W
SE-101PJ-100
Note : Resistors are mounted to the location where L101,L102,
L103, L104 are printed.
Note : Resistors are mounted to the location where L452,L453 are
printed.
