Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
A-7074-193-A VF-141 BOARD, COMPLETE (TR517)
*****************************
(Ref.No.;10000 Series)
< CAPACITOR >
C4501 1-127-688-21 TANTAL. CHIP 10uF 20% 6.3V
C4503 1-107-826-91 CERAMIC CHIP 0.1uF 10% 16V
C4504 1-107-826-91 CERAMIC CHIP 0.1uF 10% 16V
C4507 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C4508 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C4509 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C4510 1-107-826-91 CERAMIC CHIP 0.1uF 10% 16V
C4511 1-164-739-11 CERAMIC CHIP 560PF 5% 50V
C4512 1-107-826-91 CERAMIC CHIP 0.1uF 10% 16V
C4513 1-107-826-91 CERAMIC CHIP 0.1uF 10% 16V
C4514 1-107-687-11 TANTAL. CHIP 3.3uF 20% 20V
C4515 1-164-357-11 CERAMIC CHIP 1000PF 5% 50V
C4516 1-162-928-11 CERAMIC CHIP 120PF 5% 50V
C4517 1-107-826-91 CERAMIC CHIP 0.1uF 10% 16V
C4518 1-109-982-11 CERAMIC CHIP 1uF 10% 10V
C4519 1-109-982-11 CERAMIC CHIP 1uF 10% 10V
C4520 1-109-982-11 CERAMIC CHIP 1uF 10% 10V
C4521 1-107-826-91 CERAMIC CHIP 0.1uF 10% 16V
C4523 1-115-566-11 CERAMIC CHIP 4.7uF 10% 10V
C4524 1-164-505-11 CERAMIC CHIP 2.2uF 16V
C4526 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C4527 1-107-725-11 CERAMIC CHIP 0.1uF 10% 16V
< CONNECTOR >
CN4501 1-764-526-11 CONNECTOR, FFC/FPC 18P
CN4502 1-750-630-11 CONNECTOR, FFC/FPC (ZIF) 16P
< DIODE >
D4502 8-713-102-80 DIODE 1T369-01-T8A
D4503 8-719-077-74 DIODE MA2S784008S0
D4504 8-719-077-74 DIODE MA2S784008S0
< FERRITE BEAD >
FB4502 1-500-329-11 INDUCTOR CHIP 0UH
FB4505 1-500-329-11 INDUCTOR CHIP 0UH
< IC >
IC4501 8-759-591-95 IC RB5P0040M1
IC4502 8-752-400-96 IC CXD3501R-T4
< COIL >
L4501 1-469-525-91 INDUCTOR 10uH
L4504 1-412-949-21 INDUCTOR 6.8uH
< TRANSISTOR >
Q4504 8-729-037-52 TRANSISTOR 2SD2216J-QR(K8).SO
< RESISTOR >
R4505 1-216-853-11 METAL CHIP 470K 5% 1/16W
R4507 1-218-895-11 METAL CHIP 100K 0.5% 1/16W
R4508 1-216-845-11 METAL CHIP 100K 5% 1/16W
R4513 1-216-835-11 METAL CHIP 15K 5% 1/16W
R4515 1-216-826-11 METAL CHIP 2.7K 5% 1/16W
R4516 1-216-841-11 METAL CHIP 47K 5% 1/16W
R4517 1-216-843-11 METAL CHIP 68K 5% 1/16W
R4518 1-216-837-11 METAL CHIP 22K 5% 1/16W
R4520 1-216-843-11 METAL CHIP 68K 5% 1/16W
R4521 1-216-857-11 METAL CHIP 1M 5% 1/16W
R4522 1-216-845-11 METAL CHIP 100K 5% 1/16W
R4524 1-216-844-11 METAL CHIP 82K 5% 1/16W
R4525 1-216-838-11 METAL CHIP 27K 5% 1/16W
R4526 1-216-809-11 METAL CHIP 100 5% 1/16W
R4527 1-216-809-11 METAL CHIP 100 5% 1/16W
R4528 1-216-809-11 METAL CHIP 100 5% 1/16W
R4529 1-216-833-91 RES-CHIP 10K 5% 1/16W
R4530 1-216-845-11 METAL CHIP 100K 5% 1/16W
R4534 1-216-864-11 METAL CHIP 0 5% 1/16W
R4542 1-216-864-11 METAL CHIP 0 5% 1/16W
R4543 1-216-864-11 METAL CHIP 0 5% 1/16W
R4544 1-216-853-11 METAL CHIP 470K 5% 1/16W
************************************************************
A-7073-838-A VF-129 (N) BOARD, COMPLETE
(TR317/TRV17/TRV37/TRV47/TRV57/TRV57P/
TRV67/TRV87/TRV87P)
**************************************
(Ref.No.;1000 Series)
< CAPACITOR >
C901 1-107-854-11 TANTAL. CHIP 68uF 20% 6.3V
C902 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C903 1-135-145-11 TANTALUM CHIP 0.47uF 10% 35V
C904 1-162-965-11 CERAMIC CHIP 0.0015uF 10% 50V
C905 1-104-752-11 TANTAL. CHIP 33uF 20% 6.3V
C906 1-162-638-11 CERAMIC CHIP 1uF 16V
C907 1-104-563-11 FILM CHIP 0.1uF 5% 16V
C908 1-162-920-11 CERAMIC CHIP 27PF 5% 50V
C909 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
0 C910 1-162-625-11 CERAMIC CHIP 0.0047uF 5% 50V
0 C911 1-164-715-11 CERAMIC CHIP 0.0068uF 5% 50V
C912 1-107-854-11 TANTAL. CHIP 68uF 20% 6.3V
C913 1-135-145-11 TANTALUM CHIP 0.47uF 10% 35V
C914 1-113-984-11 TANTAL. CHIP 1.5uF 20% 35V
C915 1-163-037-11 CERAMIC CHIP 0.022uF 10% 25V
C916 1-164-611-11 CERAMIC CHIP 0.001uF 10% 500V
< CONNECTOR >
* CN901 1-785-379-01 HOUSING, CONNECTOR
* CN902 1-580-057-11 PIN, CONNECTOR (SMD) 4P
< DIODE >
D901 8-719-951-21 DIODE PR1102W-TR
D903 8-719-073-01 DIODE MA111-(K8).S0
< IC >
IC901 8-759-196-14 IC BA7149F-E2
VF-141 VF-129
Note :
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
Note :
Les composants identifiés par
une marque 0 sont critiques
pour la sécurité.
Ne les remplacer que par une
pièce portant le numéro spécifié.
