6-34
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
< COIL >
L901 1-412-031-11 INDUCTOR CHIP 47uH
L902 1-410-387-11 INDUCTOR CHIP 33uH
0 L903 1-411-697-11 COIL, FERRITE (HLC)
< TRANSISTOR >
Q901 8-729-230-63 TRANSISTOR 2SD1819A-QRS-TX
Q902 8-729-106-68 TRANSISTOR 2SD1615-T1GLGK
Q903 8-729-216-31 TRANSISTOR 2SA1163G-TE85L
Q904 8-729-230-63 TRANSISTOR 2SD1819A-QRS-TX
< RESISTOR >
R901 1-216-817-11 METAL CHIP 470 5% 1/16W
R902 1-216-817-11 METAL CHIP 470 5% 1/16W
R903 1-216-055-00 METAL CHIP 1.8K 5% 1/10W
R904 1-216-833-91 RES-CHIP 10K 5% 1/16W
R905 1-216-822-11 METAL CHIP 1.2K 5% 1/16W
R906 1-216-823-11 METAL CHIP 1.5K 5% 1/16W
R907 1-216-845-11 METAL CHIP 100K 5% 1/16W
R908 1-216-852-11 METAL CHIP 390K 5% 1/16W
R909 1-216-833-91 RES-CHIP 10K 5% 1/16W
R910 1-216-835-11 METAL CHIP 15K 5% 1/16W
R911 1-216-160-00 RES-CHIP 27 5% 1/8W
R912 1-216-857-11 METAL CHIP 1M 5% 1/16W
R915 1-218-879-11 METAL CHIP 22K 0.5% 1/16W
R917 1-218-891-11 METAL CHIP 68K 0.5% 1/16W
R918 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R919 1-216-843-11 METAL CHIP 68K 5% 1/16W
R920 1-216-837-11 METAL CHIP 22K 5% 1/16W
R921 1-216-795-11 RES-CHIP 6.8 5% 1/16W
R922 1-216-850-11 METAL CHIP 270K 5% 1/16W
R923 1-216-857-11 METAL CHIP 1M 5% 1/16W
R924 1-216-862-11 RES-CHIP 2.7M 5% 1/16W
R925 1-216-862-11 RES-CHIP 2.7M 5% 1/16W
R926 1-216-821-11 METAL CHIP 1K 5% 1/16W
R927 1-216-821-11 METAL CHIP 1K 5% 1/16W
R928 1-216-827-11 METAL CHIP 3.3K 5% 1/16W
R929 1-216-821-11 METAL CHIP 1K 5% 1/16W
R930 1-216-791-11 METAL CHIP 3.3 5% 1/16W
R931 1-217-671-11 METAL CHIP 1 5% 1/10W
R932 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
< VARIABLE RESISTOR >
RV903 1-238-852-11 RES, ADJ, CERMET 470
RV904 1-238-095-11 RES, ADJ, CERMET 470K
< TRANSFORMER >
0 T901 1-453-124-11 TRANSFORMER ASSY, FLYBACK
< FLAT CABLE >
0 W901 1-540-019-21 SOCKET ASSY, CRT
************************************************************
A-7074-130-A VL-29 BOARD, COMPLETE
(TRV17/TRV37/TRV57/TRV57P/
TRV67/TRV87/TRV87P)
**************************************
(Ref.No.;1000 Series)
< CAPACITOR >
C151 1-115-566-11 CERAMIC CHIP 4.7uF 10% 10V
C153 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
< CONNECTOR >
CN151 1-766-644-21 CONNECTOR, FFC/FPC 8P
< COIL >
L151 1-416-344-11 INDUCTOR 10uH
< TRANSISTOR >
Q151 8-729-043-94 TRANSISTOR CPH3106-PM-TL
Q152 8-729-028-26 TRANSISTOR 2SK1829(TE85L)
< RESISTOR >
R151 1-216-845-11 METAL CHIP 100K 5% 1/16W
R152 1-216-864-11 METAL CHIP 0 5% 1/16W
R153 1-216-813-11 METAL CHIP 220 5% 1/16W
R154 1-216-821-11 METAL CHIP 1K 5% 1/16W
************************************************************
MISCELLANEOUS
**************
1 1-517-857-11 LIGHT, VIDEO
(TRV17/TRV37/TRV57/TRV57P/TRV67/TRV87/TRV87P)
13 1-694-384-11 TERMINAL BOARD, BATTERY
15 1-672-663-21 FP-49 FLEXIBLE BOARD(TRV87/TRV87P)
21 1-467-574-21 REMOTE COMMANDER (RMT-708)
23 1-672-670-11 FP-43 FLEXIBLE BOARD
51 1-475-621-11 SWITCH BLOCK, CONTROL(MR-8500)
55 1-791-948-11 CABLE, FLEXIBLE FLAT (FFC-001)
58 1-672-668-21 FP-62 FLEXIBLE BOARD(TRV87/TRV87P)
101 1-475-621-11 SWITCH BLOCK, CONTROL(MR-8500)
104 1-791-948-11 CABLE, FLEXIBLE FLAT (FFC-001)
108 1-803-844-81 DISPLAY PANEL, LIQUID CRYSTAL
(TR317/TR517)
152 1-676-300-11 FP-152 FLEXIBLE BOARD
154 1-960-161-11 HARNESS (DP-78)
168 1-803-844-81 DISPLAY PANEL, LIQUID CRYSTAL
(TRV17/TRV37/TRV47/TRV57/TRV57P/TRV67)
214 1-418-758-21 SWITCH BLOCK, CONTROL (SS-9700)
217 1-676-298-11 FP-150 FLEXIBLE BOARD
221 1-418-760-11 SWITCH BLOCK, CONTROL (FK-8500)
(TRV87/TRV87P)
221 1-418-760-21 SWITCH BLOCK, CONTROL (FK-8500)
(TR317/TR517/TRV17/TRV37/TRV47/
TRV57/TRV57P/TRV67)
225 1-672-673-11 FP-46 FLEXIBLE BOARD
(TRV17/TRV37/TRV57/TRV57P/TRV67/TRV87/TRV87P)
227 1-676-296-11 FP-147 FLEXIBLE BOARD
VF-129 VL-29
Note :
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
Note :
Les composants identifiés par
une marque 0 sont critiques
pour la sécurité.
Ne les remplacer que par une
pièce portant le numéro spécifié.
