4-10
DNW-A75/A75P
SERVO/DT ADJUST
A00-01:SERVO ADJUST
A02:ANALOG DT ADJUST
*
ANALOG DT ADJUST
A030:HEAD OFFSET LEVEL
A031:DRIVE GAIN
A032:DATA SAVE
*
[SET]
[MENU]
A0: SERVO/DT ADJUST
This submode is used to adjust the servo and analog DT system.
A00-01: SERVO ADJUST
This mode is used to adjust the servo system. For more details, refer to Section 4-2-7 (on page 4-46).
Title Page Description
A000 : A001-A008 ADJ. 4-47 Continuously executes the automatic adjustment menus (A001 to
A008).
A001 : S REEL FG DUTY 4-48 Automatically adjusts the duty ratio of an S reel FG.
A002 : T REEL FG DUTY 4-48 Automatically adjusts the duty ratio of a T reel FG.
A003 : CAPSTAN FG DUTY 4-48 Automatically adjusts the duty ratio of a capstan FG.
A004 : S REEL OFFSET/FRIC 4-48 Automatically adjusts the S reel offset and friction.
A005 : T REEL OFFSET/FRIC 4-48 Automatically adjusts the T reel offset and friction.
A006 : S REEL TORQUE 4-48 Automatically adjusts the S reel torque.
A007 : T REEL TORQUE 4-48 Automatically adjusts the T reel torque.
A008 : S/T TENSION OFFSET 4-48 Automatically adjusts the tension regulator offset values on the S and T
sides.
A010 : CAPSTAN FREE SPEED 4-49 Automatically adjusts the capstan free speed.
A011 : RF SWITCHING POS. 4-50 Automatically adjusts the RF switching position.
A012 : NV-RAM CONTROL 4-52 Saves the adjustment data in a servo system.
A02: ANALOG DT ADJUST
This mode is used to adjust the analog DT system. For more details, refer to Section 4-2-8 (on page 4-53).
Title Page Description
A030 : HEAD OFFSET LEVEL 4-53 Adjusts the offset level of an analog Betacam PB head.
A031 : DRIVE GAIN 4-55 Adjusts the drive gain of an analog DT system.
A032 : DATA SAVE 4-57 Saves the adjustment data in an analog DT system.
4-2. TAPE Maintenance Mode (M0)
4-2-1. Overviews
SERVO/DT ADJUST
A00-01:SERVO ADJUST
A02:ANALOG DT ADJUST
*
PREVIOUS
SERVO ADJUST (CONTINUED)
PREVIOUS
A010:CAPSTAN FREE SPEED
A011:RF SWITCHING POS.
A012:NV-RAM CONTROL
*
SERVO ADJUST
A000:A001-A008 ADJ.
A001:S REEL FG DUTY
A002:T REEL FG DUTY
A003:CAPSTAN FG DUTY
A004:S REEL OFFSET/FRIC
A005:T REEL OFFSET/FRIC
A006:S REEL TORQUE
A007:T REEL TORQUE
A008:S/T TENSION OFFSET
CONTINUE
*
CONTINUE
[SET]
[MENU]
