4-11
DNW-A75/A75P
RF ADJUST MODE
A11:EQUALIZER
A12:REC CURRENT
A13:PLAY PLL
A14:FWD PLL
A15:REV PLL
A16:A/D GAIN
A17:A11-A16 ALL ADJUST
A1F:NV-RAM CONTROL
*
A1 : RF ADJUST
This submode is used to adjust the RF system.
For more details, refer to Section 4-2-9 (on page 4-58).
Title Page Description
A11 : EQUALIZER 4-58 Automatically adjusts the PB head playing back level and PB equalizer
(for A1, A2, A5, A6, B1, B2, B5, B6, CNFA, and CNFB channels).
A12 : REC CURRENT 4-58 Automatically adjusts the recording current.
A13 : PLAY PLL 4-58 Automatically adjusts the PB PLL circuit (in the PLAY mode).
A14 : FWD PLL 4-58 Automatically adjusts the PB PLL circuit (in the FORWARD mode).
A15 : REV PLL 4-58 Automatically adjusts the PB PLL circuit (in the REVERSE mode).
A16 : A/D GAIN 4-58 Automatically adjusts the gain when a PB RF signal is converted from
analog to digital.
A17 : A11-A16 ALL ADJUST 4-63 Continuously executes the above automatic adjustment menus A11
to A16.
A1F : NV-RAM CONTROL 4-65 Saves the adjustment data in an RF system.
4-2. TAPE Maintenance Mode (M0)
4-2-1. Overviews
