4-12
DNW-A75/A75P
A2 : AUDIO/VIDEO ADJUST
This submode is used to adjust the audio and video systems.
For more details, refer to Section 4-2-10 (on page 4-66).
Title Page Description
A20 : VPR VR 4-67 Adjusts the reference signal system and analog video output system
on the VPR-47 board.
A21 : AD VR 4-68 Adjusts the analog component video input system.
A22 : AD VR (LOOP) 4-68 Adjusts the analog component video input system (in the multi-loop
state).
A23 : SDI/SDTI VR 4-69 Adjustment menu for the SDI and SDTI input/output interfaces
A231 : SDI ENC1 VCO 4-69 Automatically adjusts the SDI output interface.
A232 : SDI ENC2 VCO 4-69 Automatically adjusts the SDI output interface.
A233 : SDI DEC VCO 4-69 Automatically adjusts the SDI input interface.
A234 : SDTI ENC VCO 4-69 Automatically adjusts the SDTI (SX) output interface.
(Used for BKNW-118.)
A235 : SDTI-CP ENC VCO 4-69 Automatically adjusts the SDTI-CP output interface.
(Used for BKNW-124.)
A24 : INPUT CF DETECT 4-71 Automatically adjusts the color frame detection timing of a composite
video input.
A25 : DEC VR 4-73 Adjusts the composite video input system.
A26 : DEC VR (LOOP) 4-73 Adjusts the composite video input (in the multi-loop state).
A2F : NV-RAM CONTROL 4-74 Saves the adjustment data in audio and video systems.
4-2. TAPE Maintenance Mode (M0)
4-2-1. Overviews
AUDIO/VIDEO ADJUST MODE
A20:VPR VR
A21:AD VR
A22:AD VR (LOOP)
A23:SDI/SDTI VR
A24:INPUT CF DETECT
A25:DEC VR
A26:DEC VR (LOOP)
A2F:NV-RAM CONTROL
*
