Sony DNW-A75 - Page 218

B-4
DNW-A75/A75P
Switches on the board
n
Never change the setting of Factory use switches.
Board Switch No.: Name Factory setting Setting
AU-260 S500 : CH-1 head tune Adjusted condition _
S600 : CH-2 head tune Adjusted condition _
DM-89 S101 : Y-RF LPF & EQ TEST NORMAL POSITION _
S102 : Factory use NORMAL POSITION _
S301 : C-RF LPF & EQ TEST NORMAL POSITION _
S302 : Factory use NORMAL POSITION _
S501 : Factory use ON _
S901 1 _ 4: Factory use OFF (OPEN) _
TBC-23A S1 1 : Y MUTE OFF (OPEN)
2 : C MUTE OFF (OPEN)
3 : Factory use OFF (OPEN) _
4 : Factory use OFF (OPEN) _
5 : COMB OFF (OPEN)
6 : TBC TEST OFF (OPEN) _
7 : Factory use OFF (OPEN) _
8 : VIDEO PHASE OFF (OPEN)
S500 1 _ 4: Factory use OFF (OPEN) _
SS-83 S101 1
*1
: FLASH MEMORY OFF (OPEN) _
2 : ANA AUTO-TRACKING OFF (OPEN)
3 : ANA DISABLE OFF (OPEN)
4
*2
: SV ERR DISABLE OFF (OPEN) _
S1100 1 : EXTEND MENU OFF (OPEN)
2 : MAINTE MODE OFF (OPEN)
3 : Factory use OFF (OPEN) _
4 : RS232C DEBUG OFF (OPEN)
5 _ 8 : Factory use OFF (OPEN) _
S1102 Never change the settings of S1102 switch since each switch is set according to the characteristics of the unit.
1, 2 : Factory use OFF (OPEN) _
3 _ 6 : Model ID DNW-A75/A75P TTV 4075 N/4075 P
3 OFF (OPEN) ON (CLOSE) _
4 _ 6 OFF (OPEN) OFF (OPEN) _
7 : J/UC ON (CLOSE) _
8 : 525/625 DNW-A75: OFF (OPEN) _
DNW-A75P: ON (CLOSE) _
S1900 1 _ 8: Factory use OFF (OPEN) _
S2100 1 _ 8: Factory use OFF (OPEN) _
S2701 1 : Factory use OFF (OPEN) _
2 : DT MODE OFF (OPEN)
3, 4 : Factory use OFF (OPEN) _
*1, *2: Never change the switches S101-1 and S101-4.
