DNW-A75/A75P
Specifying the Menu (Mode) and Item
How to specify the menu (mode) and item using the search dial (JOG mode) is described below with the
mode selection given as an example.
4-1. Overview of Maintenance Mode
TAPE MAINTENANCE MODE
C0 : SERVO/DT CHECK
C1 : RF CHECK
C2 : AUDIO/VIDEO CHECK
C3 : BETACAM PB CHECK
A0 : SERVO/DT ADJUST
A1 : RF ADJUST
A2 : AUDIO/VIDEO ADJUST
A3 : BETACAM PB ADJUST
A4 : MECHANISM ADJUST
*
TAPE MAINTENANCE MODE
C0 : SERVO/DT CHECK
C1 : RF CHECK
C2 : AUDIO/VIDEO CHECK
C3 : BETACAM PB CHECK
A0 : SERVO/DT ADJUST
A1 : RF ADJUST
A2 : AUDIO/VIDEO ADJUST
A3 : BETACAM PB ADJUST
A4 : MECHANISM ADJUST
*
Turn search dial
2
Turn search dial
3
Turn search dial
2
3
Turn search dial
Turn search dial
2
3
Turn search dial
Turn search dial
2
3
Turn search dial
Turn search dial
2
Turn search dial
3
Turn search dial
2
Turn search dial
3
Press [SET]
button
Press [MENU] button Press [MENU] button
Press [SET]
button
Press [MENU] button Press [MENU] button
Turn the search dial to move the “*” mark.
Move the “*” mark to the mode (menu) which
you wish to open and press the SET button.
The mode (menu) is then opened.
Turn the search dial to display each mode (menu)
in the same row.
Display the mode (menu) which you wish to open
and press the SET button.
The mode (menu) is then opened.
M0 -TAPE MAINTEN M2 -ERROR LOGGER M3 -OTHERS
C0 -SERVO/DT CHE C1 -RF CHECK
Example in Superimpose Picture
Example in Time Data Display Area
MAINTENANCE MODE
M0 : TAPE MAINTENANCE
M2 : ERROR LOGGER
M3 : OTHERR
M4 : SETUP MAINTENANCE
*
MAINTENANCE MODE
M0 : TAPE MAINTENANCE
M2 : ERROR LOGGER
M3 : OTHER
M4 : SETUP MAINTENANCE
*
MAINTENANCE MODE
M0 : TAPE MAINTENANCE
M2 : ERROR LOGGER
M3 : OTHER
M4 : SETUP MAINTENANCE
*
