2-37
DSR-70/70P
1
2
3
4
FEDCBA
S201
1
2
3
4
ABCDEF
S101
SY-269 Board
SY-269 Board (A Side)
SY-269 Board (B Side)
Switch
Note : The switches of S201-7 through S201-8 are adjusted in accordance with the characteristics of the respective
equipment. Set these switches only when the SY-269 board is exchanged.
Never change the factory setting of the switches that are marked with “Factory use”.
Ref No. Name Description Factory Setting
S101 SYSTEM RESET Press to reset the system control operation. _
S201-1 to Factory use OFF
S201-6
S201-7 J/UC OFF : For the models outside Japan OFF
ON : For Japanese model
S201-8 525/625 OFF : 525/60 models OFF (for DSR-70)
ON : 625/50 model ON (for DSR-70P)
To Next Page
