2-38
DSR-70/70P
1
2
3
4
FEDCBA
S101
SV-203 Board
SV-203 board (A Side)
Switch
Note : S201 is operated only during adjustment.
Never change the factory setting of the switches that are marked with “Factory use”.
Ref No. Name Description Factory Setting
S101-1 Factory use Used during adjustment in factory. OFF
OFF : Normal operation
ON : Adjustment position
S101-2 no use OFF
S101-3 Factory use Turns ON/OFF the top/end sensor. OFF
OFF : Normal operation
ON : Disables the top/end sensor.
S101-4 Factory use Turns ON/OFF the error detection. OFF
OFF : Error is detected. (Normal operation)
ON : Error is not detected. (Used during adjustment)
S101-5 Factory use Sets the DVCAM/DV fixed mode. OFF
OFF : Normal operation
ON : The system operates in the mode set by S101-6.
S101-6 Factory use When S101-5 is ON. OFF
OFF : DVCAM mode
ON : DV mode
S101-7 Factory use Turns ON/OFF the prohibition of mechanism operation. OFF
OFF : Normal operation
ON : Prohibits the mechanism operation.
S101-8 Designer use _ OFF
To Next Page
