318 EDIT RETRY When editing with two DSR-70/70P units, set for the recorder. Selects the operation if
the recorder was not synchronized in time.
OFF: Editing is not carried out, and the unit stops.
ON: The editing is automatically retried (up to twice).
327 AUDIO MODE
CHANGE
Select whether to allow audio data recorded on tape in two-channel mode (or four-
channel) to be re-recorded in four-channel (or two-channel mode).
OFF: Do not allow re-recording in a different audio mode.
ON: Allow re-recording in a different audio mode.
Item number Item name Settings
401 FUNCTION MODE
AFTER CUE-UP
Select the state that the unit goes into after a cuing-up operation.
STOP: Stops (the STOP mode).
STILL: Still playback (in search mode).
Menu items in the 400s, relating to preroll
403 AUTOMATIC
PREROLL
REFERENCE
ENTRY
Select whether or not the edit IN point is automatically set by pressing the PREROLL
button when the IN point is not set before starting preroll.
DIS: IN point is not set automatically.
ENA: I N point is set automatically.
Item number Item name Settings
501 STILL TIMER Select the time delay from the tape transport stopping (either the "STOP" mode" or the
still playback mode in search mode) until the unit automatically switches to the tape
protection mode, in order to protect the rotary heads and the tape.
0.5S...
8M ...30M: Set the value in the range 0.5 seconds to 30 minutes.
Menu items in the 500s, relating to tape protection
502 TAPE
PROTECTION
MODE FROM
SEARCH
Select the operation of the protection mode to protect the rotary heads and tape when in
the still playback mode in search (jog/shuttle) mode.
STEP: Step forward at
1
/
30
normal speed every 2 seconds.
STDBY: Switch to Standby OFF mode (the unit not on standby).
Menu items in the 300s, relating to editing operations (continued)
308 SELECTION OF
STD/NON-STD
FOR ANALOG
VIDEO IN
Select the STD or NON-STD mode in accordance with a composite video or S-video
input.
STD: The STD mode is always used (forced STD mode).
N-STD: Use this setting when the input video signal is unstable (forced NON-STD
mode).
When using a VCR with no built-in time base corrector (e.g. a home-use VHS-system
VCR), select N-STD.
Chapter 7 Setup Menu
Chapter 7 Setup Menu
109
Item number Item name Settings
605 TCG REGEN
MODE
Select the signal to be regenerated when the time code generator is in the regeneration
mode (i.e., when the PRESET/REGEN item in the sub LCD menu general settings page
is set to REGEN, or the unit is in automatic edit mode).
TC&UB: Both the timecode and user bits are regenerated.
TC: Only the timecode is regenerated.
UB: Only the user bits are regenerated.
Menu items in the 600s, relating to the time code generator
607 U-BIT BINARY
GROUP FLAG
610 REGEN
CONTROL MODE
When editing with two DSR-70/70P units, if you use the control panel for editing
operation, select whether or not the timecode is automatically regenerated.
AS&IN: In editing with this unit as the recorder, regardless of the settings of the TC INT/
EXT switch and sub LCD menu item PRESET/REGEN, in assemble and insert editing ,
the timecode generator regenerates according to the timecode on the tape.
ASSEM: In editing with this unit as the recorder, regardless of the settings of the TC
INT/EXT switch and sub LCD menu item PRESET/REGEN, in assemble editing only,
the timecode generator regenerates according to the timecode on the tape.
MANU: Regardless of whether this unit is the recorder or player, the timecode
generator operates in accordance with the settings of the TC INT/EXT switch and sub
LCD menu item PRESET/REGEN.
FULL: Regardless of the REMOTE/LOCAL switch setting, when any of the ASSEMBLE,
VIDEO, AUDIO CH1,1/2, AUDIO CH2,3/4, and TC buttons is lit, the timecode generator
regenerates according to the timecode played back from the tape.
611 TC OUTPUT
PHASE IN EE
MODE
Select the timecode output mode for output from the TC OUT connector in E-E mode.
MUTE: Mute the output.
THRU: Output the timecode input to the TC IN connector as it is.
V-IN: Output the timecode with the same phase as the input video signal phase.
V-OUT: Output the timecode with the same phase as the output video signal phase.
612 TC OUTPUT
MUTE IN
SEARCH MODE
Select whether to mute the output from the TC OUT connector in search (jog/shuttle)
mode.
ON: Mute.
OFF: Do not mute.
Select the user bits to be used in the time code generated by the time code generator.
000: Character set not specified.
001: 8-bit characters compliant with ISO 646 and ISO 2022.
010: Undefined.
011: Undefined.
100: Undefined.
101: SMPTE 262M page/line multiplex system.
110: Undefined.
111: Undefined.
