4.3: INPUT CHANNEL > DYNAMICS
Vi3000 USER MANUAL
®
4.3 INPUT CHANNEL > De Esser
Input Level
Meter
Shows the input level
at the selected point in
the input channel signal
path.
The overload (OVL) LED indicates an overloaded ana-
logue input (mic preamp clipping).
Input Gain Re-
duction Meter
Shows the overall gain
reduction of the limiter
and compressor stages,
if they are engaged.
Vi3000 USER MANUAL
®
12.1 12.1: METERING > INPUTS
12.1: METERING > INPUTS
Each input channel has an input meter and every input meter has two parts: A 20--segment level meter (top), and a
9-segment Gain Reduction Meter (GRM).
Both the measured point in the channel signal ow and the metering peak hold time can be selected in the main set-
tings screen (via the [MENU] button), in the (Settings) tab.
Input Channel Metering
