7.3 7.3: OUTPUTS > BUS MASTER CONTROL
7.3: OUTPUTS > BUS MASTER CONTROL
Master Bay output channel strips
Bus masters levels can be mapped to the eight Master Bay faders and associated channel strip controls by selecting
Master Bay FADER PAGES buttons [A] (Busses 1-8), [B] (Busses 9-16), and [C] (Busses 17-24).
All Busses Mode
If the All Busses mode is active, achieved by pressing the [ALL BUSS] button in the Master Bay INPUT FADER PAG-
ES controls, the input strips on all of the input bays will be switched to control the 24 output busses and the faders will
control the bus master output levels.
Third Input Bay - Fast-Select
By touching any of the channel metering areas in the Master Bay touch screen area you assign that bank of eight to
the third input bay. Three banks of eight outputs are located on the top row on the Master Bay touch screen.
Bus Parameter Control
With the console in All Busses mode, the console’s Vistonics screens give direct touch access to the processing
chains of all 24 output buss channel strips.
Alternatively, with the Master Bay Vistonics button function set to [SOLO/SEL], pushing any bus master chanel strip
[SOLO/SEL] button will display that bus output’s processing chain in the Master Bay touch screen area.
In both cases, selecting a processing block will bring that block’s parameters up on the VST area of the Vistonics
screen.
