SoundCraft Vi3000 User Manual

4.3: INPUT CHANNEL > DYNAMICS
Vi3000 USER MANUAL
®
4.3 INPUT CHANNEL > De Esser
Vi3000 USER MANUAL
®
2.0  2.0:Vi3000Specications
 2.0:Vi3000Specications
External Sync BNC Wordclock, Dante network clock
Input & Output Levels
Mic/lineInputs   +28dBu max
LineOutputs   +22dBu max
NominalOperatingLevel +4dBu (-18dBFS)
Input & Output Impedances
MicInputs   2k7Ω
AllotheranalogueInputs >10kΩ
LineOutputs   <75Ω
AES/EBUOutputs  110Ω
Oscillator 20Hz to 20kHz/Pink/White Noise, variable level
Channel Filters
MicInHPFilter 80Hz xed, 12dB per octave
ChannelHPFilter 20Hz-600Hz, 18dB per octave
ChannelLPFilter 1kHz-20kHz, 18dB per octave
EQ (Inputs and Bus Outputs)
HF  20Hz-20kHz, +/-18dB, Q= 0.3-8.7 or shelving
Hi-Mid  20Hz-20kHz, +/-18dB, Q=0.3-8.7
Lo-Mid  20Hz-20kHz, +/-18dB, Q=0.3-8.7
LF  20Hz-20kHz, +/-18dB, Q= 0.3-8.7 or shelving
Metering Internal 20-segment LED bargraphs plus 9-segment gain reduction meters for all inputs and
Outputs Peak hold variable from 0-2s.
Mains Voltage Operating Range 90-264V, 47-63Hz, auto-ranging

SoundCraft Vi3000 Specifications

General

Busses	24 mono/stereo
Fader Layers	4
Touch Screens	2
Sample Rate	96 kHz
Bit Depth	24-bit
Faders Type	Motorized
Digital I/O	AES/EBU
Remote Control	Via ViSi Remote iPad app
Faders	36
EQ	4-band parametric
Output Channels	24 mono/stereo busses + matrix
Connectivity	Ethernet, USB
Mixing Channels	Up to 96
Effects	Lexicon FX engine
Routing	Fully flexible
Input Channels	Up to 96
