Vi3000 USER MANUAL
6.5.3: INPUT CHANNEL > DYNAMICS
Compression
Ratio Field / Group: RTIO Range Low Range High
Adjust the compression
ratio.
The ratio between the normal signal level and the attenu-
ated (compressed) signal level. The higher the ratio, the
more compression is applied.
1 20
Compressor
Makeup Gain Field / Group: MKUP Range Low Range High
Adjust the post-com-
pression makeup gain.
Gain applied after the compresssor to account for level
lost in compression.
-20dB +20dB
Compressor
Automatic
Makeup Gain Field / Group: MKUP Inactive Active
Activate automatic
makeup gain.
When activated, this will apply makeup gain after the
compressor automatically, depending on the settings of
the Threshold and Ratio controls.
Off On
Limiter
threshold Field / Group: LIM Range Low Range High
Adjust Limiter threshold. Threshold at which the limiter is activated. -40dB -6dB
Limiter In Field / Group: LIM Inactive Active
Activate Limiter Include the Limter in the dynamics section. Out In
Limiter
Attack Time Field / Group: ATCK Range Low Range High
Adjust the Limiter attack
time.
The time taken for the limiter to reach full attentuation. 10uS 98.6mS
Limiter Release
Time Field / Group: REL Range Low Range High
Adjust the Limiter
release time.
The time taken for the limiter to return to zero attentuaion
after limiting.
5.5mS 957mS
