6.5.5 6.5.5: INPUT CHANNEL > OUTS (PAN, INSERT, DIR, DELAY)
Vi3000 USER MANUAL
6.5.5: INPUT CHANNEL > OUTS
Input Touch Screen Audio Blocks - Panning, Insert, Direct Out, Delay.
This page contains the output functions of the input channel including the panning, the routing to the mix masters, and
the insert point and the direct out paramters. The Pan can work in LR or in LCR mode. In LCR mode an additional
width function is available.
Panning Field / Group: PAN Range Low Range High
Adjusts panning to the
Master L, R, and C
busses, depending on
pan mode chosen.
If the channel is paired, the balance can be adjusted. If
the Pan {MODE} is set to LCR, an additional WIDTH eld
becomes available.
30L 30R
Panning On Field / Group: PAN Inactive Active
Activate or deactivate
the panning controls.
If PAN is set to OFF, then the level to all master busses
is the same as if pan controls are 'middled'. That is -3dB
for mono channel panning and 0dB for paired channel
balance. If PAN is set to ON then the level to the master
busses varies between 0dB and -innity. For balance
that becomes +3dB to -innity.
Off On
