SoundCraft Vi3000 User Manual

Vi3000 USER MANUAL
®
6.5.5 6.5.5: INPUT CHANNEL > OUTS (PAN, INSERT, DIR, DELAY)
®
Vi3000 USER MANUAL
6.5.5: INPUT CHANNEL > OUTS
Insert Trim Field / Group: TRIM Range Low Range High
Adjust the actual send
signal level.
Insert On Field / Group: TRIM Inactive Active
Activate the insert point. Off On
Direct Output
On Field / Group: Inactive Active
Activate the Direct
Output for this input
channel.
Off On
Direct Output
Gain Field / Group: Range Low Range High
Adjust the gain of the
channel's Direct Output.
-90dB +10dB
Direct Output
Point Field / Group:
Select the point in the
input channel's signal
path for the Direct Out-
put 'tap'.
Options are pre HPF, post-HPF/Pre-processing,
post-processing/pre-fader, or post-fader.
Direct Output
Patch
Field / Group: DIRECT
OUT Inactive Active
Select and assign phys-
ical I/O for the direct
output.
Opens a patching screen in the corresponding Vistonics
touch screen area.
Close Patch
Screen
Open Patch
Screen

SoundCraft Vi3000 Specifications

General

Busses	24 mono/stereo
Fader Layers	4
Touch Screens	2
Sample Rate	96 kHz
Bit Depth	24-bit
Faders Type	Motorized
Digital I/O	AES/EBU
Remote Control	Via ViSi Remote iPad app
Faders	36
EQ	4-band parametric
Output Channels	24 mono/stereo busses + matrix
Connectivity	Ethernet, USB
Mixing Channels	Up to 96
Effects	Lexicon FX engine
Routing	Fully flexible
Input Channels	Up to 96
