SoundCraft Vi3000 User Manual

4.3: INPUT CHANNEL > DYNAMICS
Vi3000 USER MANUAL
®
4.3 INPUT CHANNEL > De Esser
Vi3000 USER MANUAL
®
7.4 7.4: OUTPUTS > GRAPHIC EQ
7.4: OUTPUTS > GRAPHIC EQ
Bandwidth Range Low Range High
Adjust the bandwidth of
the 30 GEQ bands.
The Bandwidth units can either be Q or Octaves,
depending on the {EQ UNIT} setting in the Main Menu
(Settings Tab).
0.24Oct 0.36Oct
Flatten All Active
Flatten levels of all
bands of the currently
active GEQ to 0dB.
All GEQ
bands 0dB
GEQ In Inactive Active
Activate or deactivate
the currently selected
GEQ.
GEQ Out GEQ In
Graphic EQ
Fader Range Low Range High
Adjust the level of the
corresponding band.
The FaderGlow colour for a GEQ band is red. The centre
frequency of the band is shown in the channel label
display.
-12dB +12dB
GEQ Fader On
Button Active
Indicates which GEQ
bands are non-zero,
and attens bands.
When you adjust the level of a GEQ band, the corre-
sponding [ON] button is highlighted in red. A subsequent
press of the [ON] button will atten/null the band and turn
the [ON] light off.
Band level
0dB

SoundCraft Vi3000 Specifications

General

Busses	24 mono/stereo
Fader Layers	4
Touch Screens	2
Sample Rate	96 kHz
Bit Depth	24-bit
Faders Type	Motorized
Digital I/O	AES/EBU
Remote Control	Via ViSi Remote iPad app
Faders	36
EQ	4-band parametric
Output Channels	24 mono/stereo busses + matrix
Connectivity	Ethernet, USB
Mixing Channels	Up to 96
Effects	Lexicon FX engine
Routing	Fully flexible
Input Channels	Up to 96
