5.2 Operations Overview > Vistonics II
Buttons On/Off
If a function is assigned to a button it is displayed as shown. The 'active' state shows
the button highlighted in a lighter colour.
Open Touch
Page
If the button can open a conguration page in the Touch area it shows a '+' sign on
the button. If the conguration page is already open, the button will be labelled with a
'-' sign. Pressing the button in that state will exit the conguration page.
Inactive Fields
If an audio function block is disabled, with the background of the eld changed to
grey, the button indication will change to a darker colour.
Inactive Fields
As with other buttons on the console, the VST buttons have both a momentary and a
latching action. If a button is pressed and released within approximately one half of
a second, the control will latch. If the key is held down for longer, and then released,
the control will return to its original state as the key is released.
Please note, to allow the
presetting of controls, it is still
possible to adjust parameters
when they are greyed out.

SoundCraft Vi3000 Specifications

General

Busses	24 mono/stereo
Fader Layers	4
Touch Screens	2
Sample Rate	96 kHz
Bit Depth	24-bit
Faders Type	Motorized
Digital I/O	AES/EBU
Remote Control	Via ViSi Remote iPad app
Faders	36
EQ	4-band parametric
Output Channels	24 mono/stereo busses + matrix
Connectivity	Ethernet, USB
Mixing Channels	Up to 96
Effects	Lexicon FX engine
Routing	Fully flexible
Input Channels	Up to 96
