10.2 10.2: MONITORING > SETUP
10.2: MONITORING > SETUP
Solo-In-Place
Mode
Activate the SOLO-IN-
PLACE mode.
This is a destructive mode for use only during sound-
checks or rehearsals. When a channel is soloed in SIP
mode, all other channels are muted so that only the
soloed channel is heard, in its stereo position, at the
console’s mix outputs.
Mute Safe
Mode
Enable the Mute Safe
(SIP isolation) congu-
ration mode.
If (MUTE SAFE) is active the Mute safe state from the
Input channels can be toggled with the Channel’s SEL
Key. The state for a given channel is indicated by that
channel’s Mute Safe LED. NOTE: This conguration
mode is disabled when the setup page is exited.
MON SETUP
Mode
Activate the Monitor
Setup sub-page.
The Monitor Setup sub-page parameters become availa-
ble in the VST area of the master screen. See below for
more details.
Auto Cancel
Mode
TBC
LCR Source
Select
Select the mix master
output sources for the
monitor outputs A, B,
and HP
For the Monitor A (LCR) output you can choose LCR
and/or C; for the Monitor B and Headphone outputs you
can choose LR and/or C. This selection cannot be com-
bined with the User A or User B sources, but solo and
talkback options are concurrent.
User A / B
Source Select
Select the user-dened
output source for the
monitor outputs A, B
and HP.
Choose EITHER User A or User B as a main source
for the monitoring output. This selection cannot be
combined with the LCR, LR, or C sources, but solo and
talkback options are concurrent. Each of the monitoring
outputs has its own individual USER A / B assignment.
To Next Page
