Advanced-control timers (TIM1/TIM8/TIM20) RM0440
1088/2126 RM0440 Rev 4
Table 250 lists the internal sources connected to the tim_itr input multiplexer.
Table 251 lists the internal sources connected to the tim_etr input multiplexer.
Table 247. Interconnect to the tim_ti2 input multiplexer
tim_ti2 inputs
Sources
TIM1 TIM8 TIM20
tim_ti2_in0 TIM1_CH2 TIM8_CH2 TIM20_CH2
tim_ti2_in[1..15] Reserved
Table 248. Interconnect to the tim_ti3 input multiplexer
tim_ti3 inputs
Sources
TIM1 TIM8 TIM20
tim_ti3_in0 TIM1_CH3 TIM8_CH3 TIM20_CH3
tim_ti2_in[1..15] Reserved
Table 249. Interconnect to the tim_ti4 input multiplexer
tim_ti4 inputs
Sources
TIM1 TIM8 TIM20
tim_ti4_in0 TIM1_CH4 TIM8_CH4 TIM20_CH4
tim_ti4_in[1..15] Reserved
Table 250. TIMx internal trigger connection
TIMx TIM1 TIM8 TIM20
tim_itr0 Reserved tim1_trgo tim1_trgo
tim_itr1 tim2_trgo tim2_trgo tim2_trgo
tim_itr2 tim3_trgo tim3_trgo tim3_trgo
tim_itr3 tim4_trgo tim4_trgo tim4_trgo
tim_itr4 tim5_trgo tim5_trgo tim5_trgo
tim_itr5 tim8_trgo Reserved tim8_trgo
tim_itr6 tim15_trgo tim15_trgo tim15_trgo
tim_itr7 tim16_oc1 tim16_oc1 tim16_oc1
tim_itr8 tim17_oc1 tim17_oc1 tim17_oc1
tim_itr9 tim20_trgo tim20_trgo Reserved
tim_itr10 hrtim_out_sync2 hrtim_out_sync2 hrtim_out_sync2
tim_itr11..15 Reserved
