11.3.7 From timer (TIMx) to comparators (COMPx)
Timers (TIMx) can be used as blanking window to COMPx (x = 1...7)
The blanking function is described in Section 24.3.6: COMP output blanking.
The blanking sources are given in comparators control and status register (COMP_CxCSR)
bits BLANKSEL[2:0].
Triggering signals
Timer output signal TIMx_Ocx are the inputs to blanking source of COMPx.
Active power mode
Run, Sleep, Low-power run, Low-power sleep.
11.3.8 From internal analog source to ADC (ADCx), comparator (COMPx)
and OPAMP (OPAMPx)
Table 69 provides the ADC channels mapping on GPIOs or internal connections to
temperature sensor (VTS), internal reference voltage VREFINT, VBAT/3 or opampxint_vout.
Table 68. Interconnect 15
Comparator blanking
signal BLANKSEL[2:0]
Comparator blanking source assignment
COMP1 COMP2 COMP3 COMP4 COMP5 COMP6 COMP7
1 tim1_oc5 tim1_oc5 tim1_oc5 tim3_oc4 tim2_oc3 tim8_oc5 tim1_oc5
2 tim2_oc3 tim2_oc3 tim3_oc3 tim8_oc5 tim8_oc5 tim2_oc4 tim8_oc5
3 tim3_oc3 tim3_oc3 tim2_oc4 tim15_oc1 tim3_oc3 tim15_oc2 tim3_oc3
4 tim8_oc5 tim8_oc5 tim8_oc5 tim1_oc5 tim1_oc5 tim1_oc5 tim15_oc2
5 tim20_oc5 tim20_oc5 tim20_oc5 tim20_oc5 tim20_oc5 tim20_oc5 tim20_oc5
6 tim15_oc1 tim15_oc1 tim15_oc1 tim15_oc1 tim15_oc1 tim15_oc1 tim15_oc1
7 tim4_oc3 tim4_oc3 tim4_oc3 tim4_oc3 tim4_oc3 tim4_oc3 tim4_oc3
Table 69. Interconnect 21
ADC channel
number
ADC channel source assignment
ADC1 ADC2 ADC3 ADC4 ADC5
IN0-----
IN1 PA0 PA0
PB1/OPAMP3
_VOUT
PE14
PA8/OPAMP5
_VOUT
IN2 PA1 PA1 PE9 PE15 PA9
IN3
PA2/OPAMP1
_VOUT
PA6/OPAMP2
_VOUT
PE13
PB12/OPAMP4
_VOUT
opamp5_int
_vout
(1)
IN4 PA3 PA7 PE7 PB14 Temp sensor
