RM0440 Rev 4 499/2126
RM0440 Filter math accelerator (FMAC)
513
However, if the memory space is limited, the X1 and Y buffer areas can be overlapped, such
that each output sample takes the place of the oldest input sample, which is no longer
required:
• X2_BASE = 0;
• X1_BASE = N;
• Y_BASE = N
In this case, Y_BUF_SIZE = X1_BUF_SIZE = N + d1, so that the buffers remain in sync.
Note: The FULL_WM bitfield of X1 buffer configuration register must be programmed with a value
less than or equal to log
2
(d1), otherwise the buffer is flagged full before N input samples
have been written, and no more samples are requested. Similarly, the EMPTY_WM bitfield
of the Y buffer configuration register must be less than or equal to log
2
(d2).
The filter coefficients must be pre-loaded into the X2 buffer, using the Load X2 Buffer
function. The X1 buffer can optionally be pre-loaded with any number of samples up to a
maximum of N. There is no point in pre-loading the Y buffer, since for the FIR filter there is
no feedback path.
After configuring and initializing the buffers, the FMAC_CR register should be programmed
according to the method used for writing and reading data to and from the FMAC memory.
Three methods are supported:
• Polling: No DMA request or Interrupt request is generated. Software must check that
the X1_FULL flag is low before writing to WDATA, or that the Y_EMPTY flag is low
before reading from RDATA.
• Interrupt: The interrupt request is asserted while the X1_FULL flag is low, for writes, or
when the Y_EMPTY flag is low, for reads.
• DMA: DMA requests are asserted on the DMA write channel while the X1_FULL flag is
low, and on the read channel while the Y_EMPTY flag is low.
Different methods can be used for read and for write. However it is not recommended to use
both interrupts and DMA requests for the same operation
(a)
. The valid combinations are
listed in Table 117.
a. If both interrupts and DMA requests are enabled then only DMA should perform the transfer.
Table 117. Valid combinations for read and write methods
WIEN RIEN DMAWEN DMAREN Write Read
0 0 0 0 Polling Polling
0 1 0 0 Polling Interrupt
1 0 0 0 Interrupt Polling
1 1 0 0 Interrupt Interrupt
0 0 0 1 Polling DMA
0 0 1 0 DMA Polling
0011DMADMA
0 1 1 0 DMA Interrupt
1 0 0 1 Interrupt DMA
