Peripherals interconnect matrix RM0440
398/2126 RM0440 Rev 4
Table 76. Interconnect 5
Timer
TI2 input
signal
Timer TI2 signals assignment
TIM1 TIM2 TIM3 TIM4 TIM5 TIM8 TIM15 TIM20
timx_
ti2_in0
TIM1
external
TI2 input
pins
TIM2
external
TI2 input
pins
TIM3
external
TI2 input
pins
TIM4
external
TI2 input
pins
TIM5
external
TI2 input
pins
TIM8
external
TI2 input
pins
TIM15
external
TI2 input
pins
TIM20
external
TI2 input
pins
timx_
ti2_in1
- comp1_out comp1_out comp1_out comp1_out - comp2_out -
timx_
ti2_in2
- comp2_out comp2_out comp2_out comp2_out - comp3_out -
timx_
ti2_in3
- comp3_out comp3_out comp3_out comp3_out - comp6_out -
timx_
ti2_in4
- comp4_out comp4_out comp4_out comp4_out - comp7_out -
timx_
ti2_in5
- comp6_out comp5_out comp5_out comp5_out - - -
timx_
ti2_in6
- - comp6_out comp6_out comp6_out - - -
timx_
ti2_in7
- - comp7_out comp7_out comp7_out - - -
Table 77. Interconnect 6
Timer TI3
input signal
Timer TI3 signals assignment
TIM1 TIM2 TIM3 TIM4 TIM5 TIM8 TIM20
timx_
ti3_in0
TIM1
external TI3
input pins
TIM2
external TI3
input pins
TIM3
external TI3
input pins
TIM4
external TI3
input pins
TIM5
external TI3
input pins
TIM8
external TI3
input pins
TIM20
external TI3
input pins
timx_
ti3_in1
- comp4_out comp3_out comp5_out - - -
Table 78. Interconnect 7
Timer TI4
input signal
Timer TI4 signals assignment
TIM1 TIM2 TIM3 TIM4 TIM5 TIM8 TIM20
timx_
ti4_in0
TIM1
external TI4
input pins
TIM2
external TI4
input pins
TIM3
external TI4
input pins
TIM4
external TI4
input pins
TIM5
external TI4
input pins
TIM8
external TI4
input pins
TIM20
external TI4
input pins
timx_
ti4_in1
- comp1_out - comp6_out - - -
timx_
ti4_in2
- comp2_out - - - - -
