General-purpose timers (TIM15/TIM16/TIM17) RM0440
1350/2126 RM0440 Rev 4
Table 291 and Table 292 list the sources connected to the tim_brk input.
Table 293 lists the internal sources connected to the tim_ocref_clr input multiplexer.
Table 291. Timer break interconnect
tim_brk inputs TIM15 TIM16 TIM17
TIM_BKIN TIM15_BKIN pin TIM16_BKIN pin TIM17_BKIN pin
tim_brk_cmp1 comp1_out comp1_out comp1_out
tim_brk_cmp2 comp2_out comp2_out comp2_out
tim_brk_cmp3 comp3_out comp3_out comp3_out
tim_brk_cmp4 comp4_out comp4_out comp4_out
tim_brk_cmp5 comp5_out comp5_out comp5_out
tim_brk_cmp6 comp6_out comp6_out comp6_out
tim_brk_cmp7 comp7_out comp7_out comp7_out
Table 292. System break interconnect
tim_sys_brk
inputs
TIM15 / TIM16 / TIM17
Enable bit in SYSCFG_CFGR2
register
tim_sys_brk0 Cortex
®
-M4 with FPU LOCKUP CLL
tim_sys_brk1 Programmable Voltage Detector (PVD) PVDL
tim_sys_brk2 SRAM parity error SPL
tim_sys_brk3 Flash ECC error ECCL
tim_sys_brk4 Clock Security System (CSS) None (always enabled)
Table 293. Interconnect to the ocref_clr input multiplexer
Timer OCREF clear
signal
Timer OCREF clear signals assignment
TIM15 TIM16 TIM17
tim_ocref_clr0 comp1_out comp1_out comp1_out
tim_ocref_clr1 comp2_out comp2_out comp2_out
tim_ocref_clr2 comp3_out comp3_out comp3_out
tim_ocref_clr3 comp4_out comp4_out comp4_out
tim_ocref_clr4 comp5_out comp5_out comp5_out
tim_ocref_clr5 comp6_out comp6_out comp6_out
tim_ocref_clr6 comp7_out comp7_out comp7_out
tim_ocref_clr7 Reserved
