General-purpose timers (TIM2/TIM3/TIM4/TIM5) RM0440
1232/2126 RM0440 Rev 4
Table 274 lists the internal sources connected to the tim_itr input multiplexer.
Table 271. Interconnect to the tim_ti2 input multiplexer
tim_ti2 inputs
Sources
TIM2 TIM3 TIM4 TIM5
tim_ti2_in0 TIM2_CH2 TIM3_CH2 TIM4_CH2 TIM5_CH2
tim_ti2_in1 comp1_out comp1_out comp1_out comp1_out
tim_ti2_in2 comp2_out comp2_out comp2_out comp2_out
tim_ti2_in3 comp3_out comp3_out comp3_out comp3_out
tim_ti2_in4 comp4_out comp4_out comp4_out comp4_out
tim_ti2_in5 comp6_out comp5_out comp5_out comp5_out
tim_ti2_in6
Reserved
comp6_out comp6_out comp6_out
tim_ti2_in7 comp7_out comp7_out comp7_out
tim_ti2_in[8..15] Reserved
Table 272. Interconnect to the tim_ti3 input multiplexer
tim_ti3 inputs
Sources
TIM2 TIM3 TIM4 TIM5
tim_ti3_in0 TIM2_CH3 TIM3_CH3 TIM4_CH3 TIM5_CH3
tim_ti3_in1 comp4_out comp3_out comp5_out Reserved
tim_ti2_in[2..15] Reserved
Table 273. Interconnect to the tim_ti4 input multiplexer
tim_ti4 inputs
Sources
TIM2 TIM3 TIM4 TIM5
tim_ti4_in0 TIM2_CH4 TIM3_CH4 TIM4_CH4 TIM5_CH4
tim_ti4_in1 comp1_out
Reserved
comp6_out
Reserved
tim_ti4_in2 comp2_out Reserved
tim_ti4_in[3..15] Reserved
Table 274. TIMx internal trigger connection
TIMx TIM2 TIM3 TIM4 TIM5
tim_itr0 tim1_trgo tim1_trgo tim1_trgo tim1_trgo
tim_itr1 Reserved tim2_trgo tim2_trgo tim2_trgo
tim_itr2 tim3_trgo Reserved tim3_trgo tim3_trgo
tim_itr3 tim4_trgo tim4_trgo Reserved tim4_trgo
