AES hardware accelerator (AES) RM0440
1518/2126 RM0440 Rev 4
A CCM message is processed through the following phases, further described in next
subsections:
• Init phase: AES processes the first block and prepares the first counter block.
• Header phase: AES processes associated data (A), with tag computation only.
• Payload phase: IP processes plaintext (P), with tag computation, counter block
encryption, and data XOR-ing. It works in a similar way for ciphertext (C).
• Final phase: AES generates the message authentication code (MAC).
CCM Init phase
In this phase, the first block B0 of the CCM message is written into the AES_IVRx register.
The AES_DOUTR register does not contain any output data. The recommended sequence
is:
1. Ensure that the AES peripheral is disabled (the EN bit of the AES_CR must be 0).
2. Select CCM chaining mode, by setting to 100 the CHMOD[2:0] bitfield of the AES_CR
register, and optionally, set the DATATYPE[1:0] bitfield.
3. Indicate the Init phase, by setting to 00 the GCMPH[1:0] bitfield of the AES_CR
register.
4. Set the MODE[1:0] bitfield of the AES_CR register to 00 or 10. Although the bitfield is
only used in payload phase, it is recommended to set it in the Init phase and keep it
unchanged in all subsequent phases.
5. Initialize the AES_KEYRx registers with a key, and initialize AES_IVRx registers with
B0 data as described in Table 322.
6. Start the calculation of the counter, by setting to 1 the EN bit of the AES_CR register
(EN is automatically reset when the calculation finishes).
7. Wait until the end of computation, indicated by the CCF flag of the AES_SR transiting
to 1. Alternatively, use the corresponding interrupt.
8. Clear the CCF flag in the AES_SR register, by setting to 1 the CCFC bit of the AES_CR
register.
CCM header phase
This phase coming after the GCM Init phase must be completed before the payload phase.
During this phase, the AES_DOUTR register does not contain any output data.
The sequence to execute, identical for encryption and decryption, is:
1. Indicate the header phase, by setting to 01 the GCMPH[1:0] bitfield of the AES_CR
register. Do not modify the MODE[1:0] bitfield as set in the Init phase.
2. Enable the AES peripheral by setting the EN bit of the AES_CR register.
3. If it is the last block and the AAD size in the block is inf
erior to 128 bits, pad the
remainder of the block with zeros. Then append the data block into AES in one of ways
Table 322. Initialization of AES_IVRx registers in CCM mode
Register AES_IVR3[31:0] AES_IVR2[31:0] AES_IVR1[31:0] AES_IVR0[31:0]
Input data B0[31:0] B0[63:32] B0[95:64] B0[127:96]
Note: In this mode, the settings 01 and 11 of the MODE[1:0] bitfield are forbidden.
