RM0440 Rev 4 1207/2126
RM0440 Advanced-control timers (TIM1/TIM8/TIM20)
1226
28.6.20 TIMx break and dead-time register (TIMx_BDTR)(x = 1, 8, 20)
Address offset: 0x044
Reset value: 0x0000 0000
Note: As the bits BKBID/BK2BID/BK2P, BK2E, BK2F[3:0], BKF[3:0], AOE, BKP, BKE, OSSI,
OSSR and DTG[7:0] can be write-locked depending on the LOCK configuration, it can be
necessary to configure all of them during the first write access to the TIMx_BDTR register.
Bits 31:20 Reserved, must be kept at reset value.
Bits 19:0 CCR4[19:0]: Capture/compare value
If channel CC4 is configured as output: CCR4 is the value to be loaded in the actual
capture/compare 4 register (preload value).
It is loaded permanently if the preload feature is not selected in the TIMx_CCMR2 register
(bit OC4PE). Else the preload value is copied in the active capture/compare 4 register when
an update event occurs.
The active capture/compare register contains the value to be compared to the counter
TIMx_CNT and signalled on tim_oc4 output.
Non-dithering mode (DITHEN = 0)
The register holds the compare value in CCR4[15:0]. The CCR4[19:16] bits are reset.
Dithering mode (DITHEN = 1)
The register holds the integer part in CCR4[19:4]. The CCR4[3:0] bitfield contains the
dithered part.
If channel CC4 is configured as input: CCR4 is the counter value transferred by the last
input capture 4 event (tim_ic4). The TIMx_CCR4 register is read-only and cannot be
programmed.
Non-dithering mode (DITHEN = 0)
The register holds the capture value in CCR4[15:0]. The CCR4[19:16] bits are reset.
Dithering mode (DITHEN = 1)
The register holds the capture in CCR4[19:4]. The CCR4[3:0] bits are reset.
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
Res. Res. BK2BID BKBID
BK2
DSRM
BK
DSRM
BK2P BK2E BK2F[3:0] BKF[3:0]
rw rw rw rw rw rw rw rw rw rw rw rw rw rw
1514131211109876543210
MOE AOE BKP BKE OSSR OSSI LOCK[1:0] DTG[7:0]
rw rw rw rw rw rw rw rw rw rw rw rw rw rw rw rw
