Instruction Manual for AS380 Series Elevator Integrated Drive Controller
Chapter 7 Parameter Table of Integrated Drive Controller
183
F164 setting
value
Load-weighing
instrument
modle
Signal acquisition method
of light-load, heavy-load,
full-load , over-load
Acquisition method of
compensation signal
0
DTZZ-III-DC-SC
Switch signal input to car
ceiling board
Input load-weighing instrument
signal through CAN, Then
calculate the final compensation
value based on the weighing
instrument signal,
F193,F194,F195
1
DTZZ-II
Input the load-weighing
instrument signal through
CAN, then calculate based on
the weighing instrument
signal.
Input the load-weighing
instrument signal through CAN
2
DTZZ-II
Switch signal input to car
ceiling board
Input the load-weighing
instrument signal through CAN
3
DTZZ-III-DC-SC
Input the load-weighing
instrument signal through
CAN, then calculate based on
the weighing instrument
signal
Input load-weighing instrument
signal through CAN, Then
calculate the final compensation
value based on the weighing
instrument signal,
F193,F194,F195
4
none
Switch signal input to car
ceiling board
Calculated the weighing
compensation value of light-load
and heavy-load based on the
light-load or heavy-load switch
signal as well as F193, F194,
F195. meanwhile, F40 set as 50%
5
Switch signal input to car
ceiling board
Input weighing instrument signal
through analog quantity.
6
Input the weighing
instrument signal through
analog quantity. And
calculate based on the
weighing instrument signal
Input weighing instrument signal
through analog quantity.
99
Switch signal input to car
ceiling board
None.
Note 1:
When F164 is 03 , the load-weighing device is model DTZZ-III-DC-SC or
DTZZ-II specialized for STEP corporation. The weighing signal is transmitted to
main board through CAN. When F164 is 4, the elevator is without electronic
weighing device but mechanic weighing switch. When F164 is 5 and 6, the elevator
weighing device is other type device. The weighing signal is transmitted into analog
