Chapter 8 Elevator Elevator Commissioning Guide
(2) Correctly power on for AIO;
(3) Confirm that the safety loop and lock loop are in a normal connected state;
(4) The Auto / Inspection (or emergency power operation) switch is in position of Inspection
(or emergency power operation):
(5) Select "induction motor self study" command by Seven-Segment Code Display
Manipulator or LCD handheld Manipulator, and then press the Enter key;
(6) AIO starts static self study: the main contactor between AIO and the motor will
automatically pull; AIO obtains internal characteristics parameters of the motor by applying
test current on the motor. But the brake contactor will not pull; neither will the motor rotate;
(7) The motor parameters complete their self study after 30 seconds, and the main contactor
releases automatically.
If the self study does not work, mainly check the following items:
(1) Whether the safety loop and the lock loop are connected. If not, the main contactor will
not pull, so it is impossible to complete the self study;
(2) Whether the Encoder wiring is correct, whether A, B phase is reversed;
(3) Whether the motor parameters are set correctly.
8.5 Test Run of Slow Car
8.5.1 Inspection Operation of Engine Room and Preparations for
Express Car
1. Points to be confirmed by the engine room before slow car run
（1）Inspection (or emergency power operation) switch of the control cabinet to "Inspection"(or
emergency power operation) position, and car top Inspection switch to "normal " position;
（2）Safety loop and lock loop work properly. Remember not to have lock shorted;
（3）Encoder properly installed and wired correctly;
（4）After powered on, the elevator integrated drive controller displays normally and checks
whether its parameters are set correctly, and manual programming shows that the elevator is
in a status of "Inspection";
（5）Connect the tractor brake line onto the terminal in the control cabinet correctly;
（6）The upper and lower slow down switches are correctly wired;
（7）Inspection priority circuit on the car top is correctly wired;
2. Operation of engine room slow car
After the engine room slow car meets the operating conditions, press the upward (downward)
button on the control cabinet, and the elevator should go upward (downward) at a preset
Inspection speed.
（1）Observe whether the elevator follows the right direction, when it goes up or down. If in the
