Instruction Manual for AS380 Series Elevator Integrated Drive Controller
Chapter 6 Introduction to the supporting products
131
JP5
standby
CH2510-4
JP6
Program burning record slot/ RS232 communication port
S1
Set the address codes of the display Board with the jumper on, after that the
jumper MUST BE REMOVED.
S2
Bridge S2.1 and S2.2 to use JP2 as the button of three-wire system,
otherwise, used as button for four wire system.
S3
Bridge S3.1 and S3.2 to use JP3 as the button of three-wire system,
otherwise, used as button for four wire system
SW1
Resistor jumper of serial communication terminal, meanwhile shorting
means the connection of built-in 120Ω resistor.
6.5.9 Miscellaneous (A List of Display Codes)
A list of performance displays
Displays in Car
No Voice Forecast
Inspection
Normal
No
Special
symbol/otherwise
Re-leveling at
power off
Normal
No
Special
symbol/otherwise
Independent
Normal
No
Special
symbol/otherwise
Fireman
Normal
No
Special
symbol/otherwise
Safety circuit
off
Normal
No
Special
symbol/otherwise
Lockout
Normal
No
Special
symbol/otherwise
Breakdown
Normal
No
Special
symbol/otherwise
Overload
Normal
No
Special
symbol/otherwise
‖oL‖on display
By-pass with
attendant
Normal
No
Special
symbol/otherwise
Full-load
Normal
No
Special
symbol/otherwise
Displays in the Landing
No Voice Forecast
Inspection
Normal
No
Special
symbol/otherwise
Re-leveling at
power off
Normal
No
Special
symbol/otherwise
