Instruction Manual for AS380 Series Elevator Integrated Drive Controller
Chapter 6 Introduction to the supporting products
Chapter 6 introduction to the supporting products
In the following Table 6.1, AS 380 series elevator integrated drive controller‗s supporting
materials are tabulated for users making choices in accordance with the specific configuration of
their elevators:
Car top Control Board SM-02/H
Collect and process car top information and other
related information
Car top Extension Board
SM.09IO/B
Control rear door open/close signal and collect
information related to rear door
required part for
rear door
Car Control Board SM.02/G
Collect and process car information and other related
information
Car extension board SM.09IO/B
Collect and process door open holding button, NS-SW
switch information
Instruction control panel SM-03
Command panel, installed in car operation panel,
collect information related car call and etc.
Call &
display
control
SM-04
For installation of call/ display panel
For installation of instruction panel and car display
board
Installed in the control cabinet, for the heat dissipation
of elevator tractor. The controller of various frequency
should be equipped with the corresponding brake
resistors
ABZ incremental 12V PG card
AS.T025
For asynchronous motor or synchronous motor with
incremental encoder
Required par as per
the encoder type
ABZ incremental 5V PG card
AS.T041
For asynchronous motor or synchronous motor with
incremental encoder
To Next Page
