Instruction Manual for AS380 Series Elevator Integrated Drive Controller
Chapter 8 Elevator Elevator Commissioning Guide
8.5.4 Door Opening/Closing Adjustment
1. Set the elevator to Inspection status and leave the lift car at the leveling position;
2. Send in door machine power;
3. Move the car door manually, monitor on the handheld Manipulator whether the door closing in
place (HX0) signal and the door opening in place (HX1) signal work correctly;
4. Confirm the safety edge signal and the overload signal are not in action;
5. Confirm F165 parameter set to 0 (door operation allowed during the elevator Inspection);
6. Have the car door in complete open state;
7. Press close button to confirm that the elevator door may close correctly until close in place;
8. Then, press the button to open the door, make sure the elevator door may open correctly until
open in position.
8.6 hoist way Self Study
Running hoist way self study means the elevator runs at self study speed and records the
position of each floor and that of each switch in the well, as the floor location is the basis for the
normal brake and operation of the elevator and for the floor display. Therefore, before the express
car operates, it is mandatory to run well self study first.
8.6.1 Hoistway Self Study Method
1．Confirm the elevator complies with safe operating conditions.
2. Confirm that all switches within the well are correctly installed and wired, and the connection
of accompanying cables and outside cables is correct;
3．Have the elevator into Inspection (or emergency electric operating) state;
4．Enter into self study menu by hand-held programmer, follow the menu instructions, and find
well self study interface. Then move the cursor to well self study command and press Enter key;
5．Set the elevator into the automatic state, and the elevator runs down to the bottom level at s
Learn trip speed (set by F183) and then automatically goes up at self study speed, and begin well
self study. Well study is complete until the elevator arrives at the top leveling position and stops
automatically. The handheld Manipulator shows "self study completed" after the success of the
self study;
6．In the self study process, if the control system is abnormal, self study will stop and give the
corresponding fault number, and the handheld Manipulator shows "self study unsuccessful".
Main reasons for unsuccessful well self study include:
（1）The total story number set (F11) is inconsistent with the number of leveling spiles
installed in the well;
（2）The number of slow down switches installed is inconsistent with the data set by
parameter F182;
（3）The upper and lower leveling switch wiring reversed;
（4）The leveling switch and leveling spiles are installed in the position not accurate enough
