Chapter 2 Model And Specification
Chapter 2 Model and Specification
This chapter introduces the model, specification, and installation dimension of AS380 series
integrated drive controller.
2.1 Model of integrated drive controller
Table 2.1 is the model list of AS380 series integrated drive controller.
Table 2.1 AS380 series integrated drive controller model list
Model AS380-
Nominal Capacity (kVA)
Nominal Output Current (A)
Applicable Motor (kW)
2S01P1
2.3
6.0
1.1
2S02P2
4.6
12
2.2
2S03P7
6.9
18
3.7
2T05P5
9.5
25
5.5
2T07P5
12.6
33
7.5
2T0011
17.9
47
11
2T0015
23
60
15
2T18P5
29
75
18.5
2T0022
32
80
22
4T02P2
4.7
6.2
2.2
4T03P7
6.9
9
3.7
4T05P5
8.5
13
5.5
4T07P5
14
18
7.5
4T0011
18
27
11
4T0015
24
34
15
4T18P5
29
41
18.5
4T0022
34
48
22
4T0030
50
65
30
4T0037
61
80
37
4T0045
74
97
45
4T0055
98
128
55
4T0075
130
165
75
2.2 The technical specification of integrated drive controller
Table 2.2 is the technical specification of AS380 series integrated drive controller.
Table 2.2 AS380 series elevator integrated drive controller technical specification
2S01P5
2S02P2
2S03P7
2T05P5
2T07P5
2T0011
2T0015
2T18P5
2T0022
4T02P2
4T03P7
4T05P5
4T07P5
4T0011
4T0015
4T0018
4T0022
4T0030
4T0037
4T0045
4T0055
4T0075
Max. applicable motor capacity (kW)
1.1
2.2
3.7
5.5
7.5
11
15
18.5
22
2.2
3.7
5.5
7.5
11
15
18.5
22
30
37
45
55
75
Nominal
output
Nominal capacity (kVA)
2.3
4.6
6.9
9.5
12.6
17.9
23
29
32
4.7
6.9
8.5
14
18
24
29
34
50
61
74
98
130
