Instruction Manual for AS380 Series Elevator Integrated Drive Controller
Chapter 8 Elevator Elevator Commissioning Guide
199
(5) Communication lines and power lines go separate trunking
(6) Group control communication lines of parallel connection and power lines go separate
trucking (only parallel connection or group control elevator)
8.3.2 Checks after Power on
1. Close the main power switch. If the green light on the phase sequence relay KAP is
on, the phase position is correct. If the green light is not on, shut off the main power
supply; swap any two-phase positions and then power on again.
2. Check all terminal voltage of the isolation transformer TCO in the control cabinet,
and see whether they are within the nominal range.
3. In the premise of carrying out the above steps correctly, proceed with the following
steps:
(1) Close the fuse
FUn
(n = 1, 2, 3 ... ...);
(2) Close the door open/close power control switch; open/close TPB is powered on,
and the motherboard is electrified to run.
Each terminal voltage of switching power supply is as follows:
Table 8.1 Terminal voltage of switching power supply
Terminal
L N
24V COM
voltage
220±7%VAC
24.0±0.3VDC
(3) Reset the emergency stop switch of the control cabinet, connect safety loop, and the LED
lights corresponding to the motherboard input point are on.
(4) Check the following circuit:
Check whether the door lock loop is normal;
Check whether the leveling switch signal is normal;
The elevator status on the handheld programmer should show "Inspection";
If abnormal, please check and correct accordingly.
Configuration of System Basic Parameters and Self Study
of Motor Parameters
8.4.1 Configuration of System Basic Parameters
First set the system basic parameters in Table 7.2 correctly through a dedicated handheld
LCD Manipulator (see Chapter 5 for the use of hand-held Manipulator), and then make
commissioning as described in the following sections. For each new system, before setting
parameters, it‘s recommended to make a parameter reset through a dedicated LCD Manipulator.
Parameter reset as follows:
(1) The elevator is in stop state;
(2) Find "parameter reset" command interface in handheld Manipulator;
