STEP AS380 Series User Manual

Shanghai STEP Electric Corporation
Chapter 8 Elevator Elevator Commissioning Guide
200
(3) Align the cursor with "parameter reset" command and press Enter key, the system will
complete parameter reset immediately.
After parameter reset, all the parameters are changed into factory default values. Configure the
basic parameters on the basis of parameter reset, and the other parameters are set to be the factory
default values, to ensure normal and reliable operation of the system.
Table 8.2 System Basic Parameters
No.
Name
Default Value
Scope
Unit
Remarks
F06
Elevator rated speed
1.750
0.100～
10.000
m/s
F09
Lockout floor
1
1～64
×
F10
Offset floor
0
0～64
×
F11
Total floor number preset
18
2～64
×
F12
Inspection speed
0.250
0～0.630
m/s
F23
Group control mode
0
0～3
×
F25
Input Type 1 (normal open or normal
closed configuration for X0 ~ X15
input point)
819
0～65535
×
F26
Input Type 2 (normal open or normal
closed configuration for X16 ~ X25
input point)
2
0～65535
×
F27
Lift car board input type (normal open
or normal closed configuration for
GX0 ~ GX15 input point)
0
0～65535
×
F28
Car top board input type (normal open
or normal closed configuration for
HX0 ~ HX15 input point)
327
0～65535
×
F182
Deceleration switch series
0
0～10
×
F183
Learn trip speed
0.800
0～1.000
m/s
F202
Motor type
0
0 / 1
×
0:
asychronous
1:
synchronous
F203
Motor rated power
According to
inverter
parameter
0．40～
160．00
KW
F204
Motor rated current
According to
inverter
parameter
0．0～300．0
A
F205
Motor rated frequency
50.00
0.00～
120.00
Hz
F206
Motor rated rotary speed
1460
0～3000
rpm
